THERMOROSSI NATURAL 12 Installation, Use And Maintenance Manual

Hide thumbs

page of 36

/ 36
Bookmarks

Quick Links

Download this manual

NATURAL 12

ITA - MANUALE DI INSTALLAZIONE, USO E MANUTENZIONE.

FRA - MANUEL D'INSTALLATION, D'UTILISATION ET D'ENTRETIEN.

ENG - INSTALLATION, USE AND MAINTENANCE GUIDE.

DEU - INSTALLATIONS-, BETRIEBS- UND WARTUNGSANLEITUNG.

ESP - MANUAL DE INSTALACIÓN USO Y MANTENIMIENTO.

NL - HANDLEIDING VOOR INSTALLATIE, GEBRUIK EN ONDERHOUD.

ITA - Informazioni importanti per la sicurezza ed il corretto funzionamento.

FRA - À lire impérativement ! Informations importantes pour la sécurité et le bon fonctionnement.

ENG - Must read! Important information for safety and correct operation.

DEU - Unbedingt lesen! Wichtige Informationen zur Sicherheit und zum sicheren Betrieb.

ESP - ¡Leer! Informaciones importantes para la seguridad y el correcto funcionamiento.

NL - Belangrijke informatie voor de veiligheid en correcte werking.

Need help?

Do you have a question about the NATURAL 12 and is the answer not in the manual?

Questions and answers

Summary of Contents for THERMOROSSI NATURAL 12

Page 1 NATURAL 12 ITA - MANUALE DI INSTALLAZIONE, USO E MANUTENZIONE. FRA - MANUEL D’INSTALLATION, D’UTILISATION ET D’ENTRETIEN. ENG - INSTALLATION, USE AND MAINTENANCE GUIDE. DEU - INSTALLATIONS-, BETRIEBS- UND WARTUNGSANLEITUNG. ESP - MANUAL DE INSTALACIÓN USO Y MANTENIMIENTO. NL - HANDLEIDING VOOR INSTALLATIE, GEBRUIK EN ONDERHOUD.
Page 3 Installation, use and maintenance guide NATURAL 12 INDEX 1 – INTRODUCTION..........................4 2 – TECHNICAL CHARACTERISTICS...................... 6 3 – GENERAL DESCRIPTION ........................8 4 – INSTALLATION ........................... 9 5 – DESCRIPTION OF THE CONTROLS ....................12 6 – USE OF THE APPLIANCE .........................18 7 –...
Page 4 DECLARATION OF PERFORMANCE ACCORDING TO REGULATION (EU) 305/2011 Codice di identificazione unico del prodotto-tipo: NATURAL 12 Modello, lotto, serie ai sensi dell'articolo 11, paragrafo 4: NATURAL 12 Unique identification code of the product type: Model, batch or serial number required under Article 11(4):...
Page 5 Furthermore, Thermorossi reserves the right to apply changes to the content of this manual anytime and without notice. Thermorossi S.p.A. retains copyright on this manual. These instructions may not be reproduced or communicated to third parties or used in any other way without the necessary authorisation.
Page 6 Installation, use and maintenance guide NATURAL 12 ATTENTION: Before every use make sure that the brazier is clean and positioned correctly in its seat, check that the ash pan is clean and that the firebox door is firmly closed and tight.
Page 7 (c) Valid for casings: Saint Moritz, Lienz, Montreux. Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Page 8 (c) Valid for casings: Saint Moritz Supreme. Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Page 9 O/I on the power panel or by cutting off the power supply. Then restart the appliance. Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Page 10 Installation, use and maintenance guide NATURAL 12 4 – INSTALLATION 4.1 APPLIANCE LOCATION Follow the general guidelines set out in paragraph 1.1 to the letter. Above all keep in mind that the floor of the installation site must be capable of bearing the weight of the appliance added to the weight of the pellets in the tank.
Page 11 See the specific manual for the casing. Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Page 12 \\tr-dc01\DatiOffice\Reparti\Tecnico\DWG\Solid_edge\PAIRPLUS 11 ERMETICA SILENT PPOWER\ articolare. Il presente disegno è di proprietà esclusiva di THERMOROSSI S. p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore. Prodotto...
Page 13 Installation, use and maintenance guide NATURAL 12 5 – DESCRIPTION OF THE CONTROLS The appliance, when operating, could be hot to the touch, particularly the door of the combustion chamber: take care when handling the appliance components. Your appliance has obtained the CE marking and has been made to run for at least one hour to check that it functions correctly.
Page 14 Installation, use and maintenance guide NATURAL 12 The following information can appear on the display: Displays the preset combustion power, and consequently the pellet consumption, by the number of bars that are lit up around the flame symbol, using this logic:...
Page 15 Installation, use and maintenance guide NATURAL 12 1) Press the Menu Button once to view the following screen: After a few seconds the following screen will appear on the display: 2) Now press the Scroll Buttons to change the day of the week; each dot corresponds to one day of the week (e.g. 1 corresponds to Monday, 2 correspond to Tuesday, etc...).
Page 16 Installation, use and maintenance guide NATURAL 12 3) Now press the Scroll Buttons to select the hour at which you wish the appliance to start up automatically (ON1). Once the hour has been set, confirm the value by pressing the Flame Button.
Page 17 Installation, use and maintenance guide NATURAL 12 For example: if I want to copy all the programmed ON/OFF cycles set for Monday to Tuesday the following screen will appear: I press the Ventilation button once again to copy all the cycles programmed for Tuesday to Wednesday. The following screen will appear: Using the same logic, we can copy the programmed cycles to the other days.
Page 18 Installation, use and maintenance guide NATURAL 12 If using loosely compressed pellets, you could select: LEVEL 0: it is an operating program that decelerates the speed of the smoke suction unit when using loosely compressed pellets and/or when the flue outlet has a very high vacuum, over 2 mm water column (20 Pascal).
Page 19 Installation, use and maintenance guide NATURAL 12 6 – USE OF THE APPLIANCE 6.1 DESCRIPTION OF THE OPERATING STAGES START: has a duration of approx. 20 minutes, during this phase the appliance is programmed to light the flame. The appliance will not accept power variations in the firebox.
Page 20 To switch off the appliance press the Flame Button until the power bars on the display disappear and the text OFF appears. Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in v DO NOT disconnect the generator from the electric power socket to switch it off.
Page 21 Termostato ambiente Room temperature thermostat Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore. Prodotto Descrizione PAIRPLUS11 STAGNA-SILENT-P.POWER...
Page 22 ATTENTION: Use N.O. (normally open) contacts for the connection to the chrono-thermostat. ATTENTION: In the event of connections to the chrono-thermostat Thermorossi shall not be held responsible for the appliance not starting up, smoke leaks and breakage of the lighting component. In the event of a programmed cycle on always ensure that the brazier is clean and seated correctly in its lodging.
Page 23 Installation, use and maintenance guide NATURAL 12 8 – CLEANING AND MAINTENANCE 8.1 FOREWORD Before beginning any maintenance operation ensure that the appliance is switched OFF and disconnected from the electric power socket. Your appliance, being a pellet-fuelled appliance, requires regular general controls and cleaning.
Page 24 Installation, use and maintenance guide NATURAL 12 ATTENTION: after cleaning it is mandatory to carefully check that the combustion chamber door is firmly closed and airtight. ATTENTION: the generator, the smoke channel and flue outlet must be cleaned in accordance with the specifications described above and use of inflammable products is strictly forbidden: using inflammable products can create dangerous situations.
Page 25 Installation, use and maintenance guide NATURAL 12 FIGURE 6 FIGURE 5 FIGURE 8 FIGURE 7 FIGURE 9 FIGURE 10 Page 24...
Page 26 Installation, use and maintenance guide NATURAL 12 8.3 REPLACING THE BUFFER BATTERY OF THE CONTROL PANEL Inside the control panel there is a buffer battery type CR1632. When the time and programming are not being memorised, then the battery needs replacing. Proceed as follows: Switch off the appliance and unplug the power cable from the power source.
Page 27 Installation, use and maintenance guide NATURAL 12 9 – SMOKE DISCHARGE TUBE AND VENTILATION OF THE ROOMS 9.1 FOREWORD Due to the frequent accidents caused by poor functioning of flue outlets installed in private dwellings, we have prepared the following paragraph to assist the installer in his inspection of the parts concerned with eliminating the gases produced by combustion.
Page 28 Installation, use and maintenance guide NATURAL 12 9.3.2 FLUE OUTLET / FLUE SYSTEM COMPONENTS Components and accessories of a chimney 1 Chimney Every chimney must have minimum number of components 2 Flow path as laid down by standard UNI EN 10683 which are also indicated in the figure on the left.
Page 29 Installation, use and maintenance guide NATURAL 12 9.3.3 CONTROLS PRIOR TO INSTALLING THE APPLIANCE The user must possess a certificate of conformance for the flue outlet (Ministerial Decree 22 January 2008, no. 37). The flue outlet must be built in compliance with UNI 10683.
Page 30 ATTENTION: The appearance of one of the alarms described below, does not necessarily imply a defect in the product, but simply Thermorossi S.p.A.’s intention to inform the user of the need for corrective actions in order to guarantee maximum safety, greater reliability and high performance of the appliance.
Page 31 Fuse 6.3A / 0.5A Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore. Page 30...
Page 32 Installation, use and maintenance guide NATURAL 12 12 – INFORMATION FOR THE SKILLED TECHNICIAN 12.1 MAIN COMPONENTS AND THEIR OPERATION SMOKE PRESSURE SWITCH This is a safety switch that stops the screw feeder motor whenever necessary. The main cause for the pressure switch tripping is a blocked flue outlet or smoke exhaust pipe.
Page 33 Installation, use and maintenance guide NATURAL 12 12.3 TROUBLESHOOTING CAUSE-SOLUTION PROBLEM POSSIBLE CAUSE SOLUTION PELLET TANK IS EMPTY CLEAN THE BRAZIER AS INDICATED IN THIS USE AND THE FOLLOWING ALARM IS SHOWN ON THE DISPLAY “NO PELLET” MAINTENANCE GUIDE, THEN FILL UP THE TANK WITH PELLETS...
Page 34 Installation, use and maintenance guide NATURAL 12 PROBLEM POSSIBLE CAUSE SOLUTION ROOM TEMPERATURE THERMOSTAT SET TOO LOW, APPLIANCE OPERATES THE APPLIANCE NEEDS TO RUN FOR MORE HOURS AT A INTERMITTENTLY HIGHER POWER; SET A HIGHER ROOM TEMPERATURE THE APPLIANCE SHOULD OPERATE FOR MORE TIME AND...
Page 35 Installation, use and maintenance guide NATURAL 12 Page 34...
Page 36 Installation, use and maintenance guide NATURAL 12 Fire Lovers Via Grumolo, 4 (Z.I.) 36011 Arsiero (VI) - ITALY Fax 0445.741657 - www.thermorossi.com - info@thermorossi.it Page 35...
