Chapter 4: BIOS Setup
PEG Port Configuration
Aptio Setup Utility - Copyright (C) 2020 American Megatrends, Inc.
Chipset
PEG Port Configuration
PEG 0:1:0 Not Present
Enable Root Port [Enabled]
Max Link Speed [Auto]
► PEG Port Feature Configuration
Version 2.20.1275. Copyright (C) 2020 American Megatrends, Inc.
Enable Root Port
Enables or disables the root port.
Max Link Speed
Configures the maximum link speed of the PEG device.
Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved.
PCH-IO Configuration
This section is used to configure PCH-IO configuration.
Enable or Disable the Root Port
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
USB Power State in S5
Configures the USB power state in S5.
State After G3
Configures the power state when power is re-applied after a power failure
(G3 state).
57
Aptio Setup Utility - Copyright (C) 2020 American Megatrends, Inc.
Chipset
PCH-IO Configuration
► SATA And RST Configuration
HD Audio Configuration
►
USB Power State in S5 [ON]
Current Power Mode ATX Mode
State After G3 [Always On]
Version 2.20.1275. Copyright (C) 2020 American Megatrends, Inc.
SATA Device Options Settings
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
