Downloads; More Information - Analog Devices ADP5589 Reference Design

When using the ZedBoard reference design in order to develop your own
software, please make sure that the following options are set in
"system_config.h":
// Select between PS7 or AXI Interface
#define USE_PS7
// SPI used in the design
#define USE_SPI
// I2C used in the design
#define USE_I2C
// Timer (+interrupts) used in the design
#define USE_TIMER
// External interrupts used in the design
#define USE_EXTERNAL
// GPIO used in the design
#define USE_GPIO

Downloads

Avnet LX-9 MicroBoard:
Reference design source code for Avnet LX9 MicroBoard.
Digilent Nexys™3:
Reference design source code for Digilent Nexys™3 Spartan-6 FPGA Board.
Avnet ZedBoard:
XPS Project
PmodIOXP Driver Files
ZYNQ SoC Peripherals Driver Files
Programming Script

More information

ask questions about the FPGA reference design
