ENG
► MINI AV
Connect the Composite cable from an external A/V Device.
Use the audio and video cables to connect the external A/V device's composite
video/audio jacks to the TV's jacks. (Video = yellow, Audio Left = White, and
Audio Right = Red)
• Press [INPUT] button, when the list of Input Source appears, press [▲/▼] to
select the source [AV] and press [OK] to connect.
Mini AV
Connection Cables are not included
► RJ45 LAN INPUT
Connect the RJ45 LAN (Local Area network) cable for connecting to external
modem or network access equipment.
Your TV will require an internet connection to operate all functions. Data
usage charges may apply.
To access the internet, you must subscribe high speed
broadband internet service from your internet service provider.
Your TV can be connected to your home network in two ways:
Wired: Using the RJ45 (LAN) connector on the back panel.
-
Wireless: Using the internal wireless or external wireless USB adapter
-
and your home wireless network.
Note: The following instructions are just the usual ways to connect your TV to the wired or
wireless network. The connection method may be different depending on your actual
network configuration. If you have any questions about your home network, please refere
to your ISP (Internet Service Provider)
VCR/DVD Player/Recorder/ Set-top
Yellow – CVBS VIDEO
White (L) - Audio
Red (R) - Audio
19
VIVAX
box/Satellite Receiver
