Texas Instruments TUSB3210 User Manual
Hide thumbs
Also See for TUSB3210:
- Data manual (44 pages) ,
- User manual (22 pages) ,
- User manual (22 pages)
Related Manuals for Texas Instruments TUSB3210
Summary of Contents for Texas Instruments TUSB3210
- Page 1 查询TUSB3210GENPDK供应商 捷多邦，专业PCB打样工厂，24小时加急出货 TUSB3210 Generic Evaluation Board User’s Guide 2001 MSP USB...
- Page 2 IMPORTANT NOTICE Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time and to discontinue any product or service without notice. Customers should obtain the latest relevant information before placing orders and should verify that such information is current and complete.
- Page 3 EVM IMPORTANT NOTICE Texas Instruments (TI) provides the enclosed product(s) under the following conditions: This evaluation kit being sold by TI is intended for use for ENGINEERING DEVELOPMENT OR EVALUATION PURPOSES ONLY and is not considered by TI to be fit for commercial use. As such, the goods being provided may not be complete in terms...
- Page 4 EVM schematic located in the EVM User’s Guide. When placing measurement probes near these devices during operation, please be aware that these devices may be very warm to the touch. Mailing Address: Texas Instruments Post Office Box 655303 Dallas, Texas 75265 Copyright 2001, Texas Instruments Incorporated...
- Page 5 Preface Read This First About This Manual This user’s guide describes the setup and operation of the TUSB3210 generic evaluation board. Familiarity with universal serial bus (USB) protocol and common laboratory testing equipment is required and assumed throughout this user’s guide.
- Page 6 Contents FCC Warning This equipment is intended for use in a laboratory test environment only. It gen- erates, uses, and can radiate radio frequency energy and has not been tested for compliance with the limits of computing devices pursuant to subpart J of part 15 of FCC rules, which are designed to provide reasonable protection against radio frequency interference.
-
Page 7: Table Of Contents
........... 1–3 TUSB3210 EVM Connected to a Compact Flash Daughterboard .... -
Page 9: Hardware And Software Required
Chapter 1 Hardware and Software Required The TUSB3210 generic EVM is designed for use with a personal computer running a USB-enabled operating system. The PC should be USB 1.1 specification compliant. This implies that the BIOS, chipsets, and operating system are all USB 1.1 specification compliant. If the BIOS is not specification compliant, the system may not boot up when USB devices are connected at power up, and the EVM may not function. -
Page 10: Equipment
This EVM is generic in the sense that it provides a 50-pin connector that allows access to the GPIO pins of the TUSB3210. It is meant to be used in conjunction with another application-specific daughterboard that connects to the 50-pin connector. -
Page 11: Tusb3210 Evaluation Board
LED (D4) provides power and suspend status to the TUSB3210 device. A USB cable should be plugged into a USB port on a PC or into a USB hub and connected to the TUSB3210 EVM type-B connector (U3). -
Page 12: Tusb3210 Printed-Circuit Board-Top Side
Hardware Overview Figure 1–4. TUSB3210 Printed-Circuit Board—Top Side... -
Page 13: 1.3 Bill Of Materials
Test point Jumper, TPS76333DBV Jumper. JP(3) Type-B USB shield USB controller, TUSB3210 MAX232 Eight-pin socket for 24LCxx 12 MHz SE3409-ND 1.4 Schematic Diagram The complete schematic diagram of the TUSB3210 generic EVM is presented at the end of this document. -
Page 15: Evm Operation
Chapter 2 EVM Operation This chapter describes the operation of the TUSB3210 EVM. Topic Page TUSB3210 Setup .......... -
Page 16: Tusb3210 Setup
EVM kit. The EVM comes in a default configuration that requires no additional components on the EVM. A full description of the TUSB3210 device is specified in the data manual. The PC must be running a USB-capable operating system. -
Page 17: Jumpers And Switches
It enumerates properly when connected to a USB host. 2.7 GPIO Connector The 50-pin GPIO connector provides access to the TUSB3210 GPIOs as well as some other control signals. Figure 2–1 shows the signals available on the connector. -
Page 18: Gpio Connector
GPIO Connector Figure 2–1. GPIO Connector P0.0 P0.1 P0.2 P0.3 P0.4 P0.5 P0.6 P0.7 P1.1 P1.0 P1.3 P1.2 P1.4 P1.5 P1.6 P1.7 P2.0 P2.1 P2.3 P2.2 P2.4 P2.5 P2.6 P2.7 P3.0 P3.1 P3.2 P3.3 P3.4 P3.5 P3.6 P3.7 SCL1 SUSP 3.3 Susp 1.8 V 3.3 V... - Page 19 GND1 P3.7 22pF 22pF GND2 22pF 100K 1 +3.3V GND3 GND4 R10 100K 1 P3.0 TUSB3210 [ If S2 or S3 tied to ground, remove 100K pull-up to save power] P3.1 +3.3V MMBT4403 0.1uF 1.2K RST# +3.3V RST# +3.3V +3.3Susp +3.3V...
