CARE AND MAINTENANCE / REPLACEMENT 3
1
2
3
IG-EX20B_EN(Singapore).indd
Plasmacluster Ion Generating Unit
(electrode section)
1 Remove the bottom
cover. (Page 10)
2 Pull out the unit holder.
Remove the dust attached to the electrode section
of the unit with an included unit cleaning brush or
commercially-available cotton applicator.
Electrode
Unit cleaning
brush (Page 5)
section
Connection
terminals
1 Inserted securely unit holder to the end.
2 Attach the bottom cover. (Page 11)
12
About once every 6 months
Unit holder
Electrode (needle)
Root of the
electrode
12
After cleaning
Click
Tab (2 places)
