1. RTL8762D Evaluation Board Introduction

1.1 RTL8762D EVB introduction

This document introduces usage of 8762D Bluetooth
hardware environment for customer to develop their own application, which includes:
1. Voltage converter.
2. 6-axis motion sensor.
3. 4 LEDs and 6 keys.
4. Button battery and Li-ion battery holder.
5. USB to UART converter (FT232RL).

1.2 Evaluation Board Interface

1.2.1 Interface Description

Distribution of EVB block and interface is shown in Figure 1-1 and Figure 1-2.
Copyright 2021 Realtek Semiconductor Corporation. All Rights Reserved.
® Evaluation Board (EVB) Hardware. 8762D EVB provides
Figure 1-1 EVB Interface Block Diagram
6
RTL8762D Evaluation Board User Manual
