FRAME IT ALL 200001090 Quick Start Manual

200001090/200002090/200003090/200004090
200001091/200002091/200003091/200004091
200001092/200002092/200003092/200004092
200001093/200002093/200003093/200004093
RAISED GARDEN BED
1 LEVEL KIT CONTAINS:
•
Composite boards 2' x 8
•
Stacking Brackets x 16
•
Stacking Stakes x 8
•
Plugs x 32
•
Caps x 8
2 LEVEL KIT CONTAINS:
•
Composite boards 2' x 18
•
Stacking Brackets x 28
•
4-way Brackets x 8
•
Stacking Stakes x 16
•
Plugs x 72
•
Caps x 8
Layout your boards along the borderline and connect each board
together by inserting the top of the stake through the bracket loops
with the stake pointing to the sky. This enables you to freely position
FOR INDOOR & HARD SURFACE:
If you plan to assemble raised bed on a hard surface, use
hacksaw to remove the spike of each stake. Use these cut
Trim stake spike with
down stakes for the base level only of your raised garden.
hacksawfor use indoor
or on hard surfaces
Customer Service: 1800-914-9835 |
support@frameitall.com
© Frame It All. All Rights Reserved.
3 LEVEL KIT CONTAINS:
•
Composite boards 2' x 26
•
Stacking Brackets x 44
•
4-way Brackets x 8
•
Stacking Stakes x 24
•
Plugs x 104
•
Caps x 8
4 LEVEL KIT CONTAINS:
•
Composite boards 2' x 36
•
Stacking Brackets x 56
•
4-way Brackets x 16
•
Stacking Stakes x 32
•
Plugs x 144
•
Caps x 8
your border to get your desired location.
ASSEMBLY INSTRUCTIONS – For the First level
STEP 1:
Assemble the boards by sliding one end of board into channel end
of one of the brackets. Use plugs to cover the holes on both sides to
lock the bracket in place.
STEP 1a:
2' x 6'
Repeat this process on the opposite end of the board flipping the bracket in
the opposite direction (see image below). Repeat for 8 boards.
STEP 2:
Layout the base level of your raised garden in a straight rectangular shape, using 8 x 2'
boards. Insert stake through the hole of the bracket and into each of the corners to lock all
sides in place.
STEP 2a: For one level, add caps to each of the top corner joints to finish off the raised garden.
ASSEMBLY INSTRUCTIONS – For Product with Two to Four Levels
STEP 3:
For the second level, connect 4 boards with a
stacking bracket on one end and a mid-section 4-
way bracket on the other end in alternating
orientation.
Then, connect 2 boards with top 4-way brackets on
both ends in alternating orientation as shown to the
right. These 3 boards will be used to install the cross
board.
Now connect 4 boards with stacking brackets on
both ends as you did for the first level.

How the Joints Work

Use a Cap to
complete the
top level.
Use stacking
stakes for
ground level
frames and
Use plugs to
stacking
cover the holes
additional levels.
– two plugs are
required per
bracket (1 on
each side)
4 x
2 x
4 x
Use stacking
Stacking stake fit
stake when
into the tops other
creating a
Stacking stakes
multi-level
Use plugs (included)
to cover the holes on
both side of boards
HAPPY GARDENING!
A
B
C
3-Way Connection:
Combining one half of a
4-way bracket and a
stacking bracket (A), will
result in a 3-way
junction (B).
