Table Of Contents - Matrix COSEC ATOM RD100 Quick Installation Manual

CONTENTS
Know your Reader
What Your Package Contains
Things You Will Need
Installing ATOM RD100
Technical Specifications
LED and Buzzer Indications
Connecting the Reader
Disposal of Product after End-Of-Life
Please read this guide first for correct installation and retain it for future reference. The information
in this guide is prevailing at the time of publication. However, Matrix Comsec reserves the right to
make changes in product design and specifications without prior notice.
Copyright
All rights reserved. No part of this document may be copied or reproduced in any form or by any
means without the prior written consent of Matrix Comsec.
Warranty
Limited Warranty. Valid only if primary protection is provided, mains supply is within limit and
protected, and environment conditions maintained within product specifications. Complete
warranty statement is available on our website:
www.matrixaccesscontrol.com
3
Know your ATOM
Ÿ
COSEC ATOM RD100 is a slave reader which can work with COSEC
4
ARGO, COSEC VEGA, COSEC PATH V2 using RS-232 and with
COSEC ARC DC200 using RS-485. It can also work with 3 party
5
Wiegand and OSDP interfaced Access Control Panel.
Ÿ
5
It is an intelligent compact Access Control Device which supports
Bluetooth and Card Credentials for
6
Attendance.
14
15
17
19
COSEC ATOM RD100 - Front View
Figure 1
1. LED indicator
2. Numeric Keypad
3. Mounting Screw Holes
4. Cable Assembly
5. Mounting Plate
Access Control and Time &
1
2
5
COSEC ATOM RD100 - Rear View
Figure 2
rd
3
4
3
4
