ADTRAN NETVANTA 3100 Series Quick Start page 3

• If the factory default switch is pressed and held for 70 seconds, a default configuration will
overwrite your existing configuration and reboot the unit. When the default configuration is
being applied, the STAT, WAN, DBU, and VPN LEDs will cycle. At this point, the default
switch can be released.
For more information on restoring factory defaults, refer to the guide
Factory Default available online at https://supportforums.adtran.com.
To factory default the unit, the default switch must be pressed WHILE the
STAT light on the front of the unit is solid green. Do not press the default
switch BEFORE the STAT light is solid green, as this will cause boot to be
missed.
F P
RONT ANEL
LED Color
STATUS Green (flashing)
(STAT)
Green (solid)
Red (solid)
Amber (solid)
ETH1 Off
(3120 only) Green (solid)
Amber (flashing)
WAN Off
(3130 only) Green (solid)
Red (solid)
Amber (solid)
VPN Off
On
DBU Off
Green (solid)
Green (flashing)
Red (solid)
Amber (solid)
SWITCH (1 Off
through 4) Green (solid)
Amber (flashing)
Quick Start Guide, 61700600L2-13E, March 2015
LED
S
Indication
The unit is powering up. On power-up, the STAT LED flashes
rapidly for five seconds.
The power is on and self-test passed.
The power is on, but the self-test failed or the boot mode (if
applicable) code could not be booted.
The unit is in bootstrap mode.
The port is administratively disabled or does not have link.
The port is enabled and the link is up.
The port has activity (transmit or receive).
The interface is administratively down.
The link is up and everything is operational.
An alarm condition is occurring on the WAN interface, or
there is a self-test failure.
The unit is in test.
No encrypted traffic.
Encrypted traffic present.
The DBU is administratively down.
The DBU is ready.
The unit is in dial backup.
An alarm condition is occurring on the DBU interface, or
there is a self-test failure.
The unit is in test.
The port is administratively disabled or does not have link.
The port is enabled and the link is up.
The port has activity (transmit or receive).
Restoring an AOS Device to
