- Page 1 Installation regulations Pure induct English...
- Page 3 Children may not play with the appliance. If you need a new power cable, always order the replacement from Brink Climate Systems B.V. To prevent dangerous situations, a damaged mains connection must only...
-
Page 4: Table Of Contents
Contents 1 Delivery........5 1.1 Delivery size. -
Page 5: Delivery
1 Delivery 1.1 Delivery size Before installation of the Pure induct appliance is started, check that it has been supplied in complete and undamaged condition. The delivery size of the appliance type Pure induct consists of the following components: 1. Air purification appliance type Pure induct 2. -
Page 6: Version
Indoors in a ventilated area under Operation conditions temperature conditions of 0 to 50 °C with a relative humidity of 0 to 90%. 2.2 Dimensions and connections A = Airflow from HRV appliance B = Airflow to home Pure induct 616141-D... -
Page 7: Exploded View Of Appliance
1 = Protection grid (2x) 2 = Ion bar air purification 3 = Mains plug and cable 230V 4 = Connector (Twist Lock) to ionbar 5 = Detachable filter lid 6 = Filter 7 = Pure induct appliance Pure induct 616141-D Brink / 7... -
Page 8: Operation
The Pure induct fits into any HVAC system, after the heat recovery unit. Once the appliance is installed and turned on, it will purify the air in your ducts. The low pressure drop of the Pure induct system makes it possible for your HVAC system to operate at a low speed. -
Page 9: Installation
▪ Never install the appliance in a place where flammable gases or liquids, or large amounts of dust may combine with air to form an explosive mixture. ▪ The Pure induct is only suited for indoor use in ventilated spaces under temperature conditions of 0 to 50 °C with a relative humidity of 0 to 90%. -
Page 10: Placing The Appliance
▪ If necessary, attach the Pure induct to the wall or ceiling using include mounting brackets Ø250 mm. ▪ Make sure the Pure induct is installed in the correct direction. The air should flow in the same direction as the air flow direction indicator on the Pure induct. -
Page 11: Starting Appliance
2. The Pure induct will then operate immediately . Switching off: ▪ Switching off mains power: 1. Pull the 230 V power plug from the electric system; the Pure induct is now free of voltage. Warning! When working on the Pure induct, always first take the voltage from the appliance by pulling the power plug. -
Page 12: Maintenance
The maintenance of the Pure induct is limited to the periodic cleaning or replacement of the filter. The filter of the Pure induct only has to be cleaned if this is indicated on the display of the HRV appliance (the... -
Page 13: Service
7 Service 7.1 Spare parts When ordering parts, in addition to the article code number, please state type Pure induct, the serial number, the year of production and the name of the part: N.B.: Appliance type, serial number and year of production are stated on the identification plate of the Pure induct... -
Page 14: Conformity Declaration
8 Conformity declaration Conformity declaration Manufacturer: Brink Climate Systems B.V. Address: Postbus 11 NL-7950 AA, Staphorst, The Netherlands Product: Type: Pure induct The product described above complies with the following directives: ¨ 2014/35/EU (low voltage directive) ¨ 2014/30/EU (EMC directive) ¨... -
Page 15: Tuv Report Tr-Kkl-2020-053-S1
9 TUV Report TR-KKL-2020-053-S1 Pure induct 616141-D Brink / 15... -
Page 16: Recycling
10 Recycling Recycling Sustainable materials are used in the manufacture of this appliance. The packaging should be disposed of in a responsible manner and in accordance with governmental regulations. Pure induct 616141-D...
