Chauvet TFX-FS360 Appendix

DMX Channel Values
Channel
1
2
Gobos
TFX-FS360 User Manual
Value Function
Color Wheel
000 031 Open
032 063 Red
064 095 Blue
096 127 Green
128 159 Yellow
160 191 Orange
191 223 Magenta
224 255 UV (Purple)
Dimmer
000 004 No Output
005 249 Closed > Open
Full Output (100%)
250 255
10
Appendix
2007-04-06/18:42
