Summary of Contents for Chauvet TRIDENT
-
Page 1: User Manual
Snapshot Use on Dimmer Outdoor Use Sound Activated Master/Slave Auto-ranging Power Supply Replaceable Fuse User Serviceable Duty Cycle User Manual 5200 NW 108th Avenue, Sunrise, FL 33351 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com... -
Page 2: Table Of Contents
ECHNICAL PECIFICATIONS ...................................... 12 ONTACT CHAUVET®, 2012, All Rights Reserved. Information and specifications in this User Manual are subject to change without notice. CHAUVET® assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. -
Page 3: Before You Begin
Manual Conventions CHAUVET® manuals use the following conventions to differentiate certain types of information from the regular text. EANING... -
Page 4: Safety Instructions
Safety Instructions Please read these instructions carefully. It includes important information about the installation, usage and maintenance of this product. • Please keep this User Manual for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. -
Page 5: Product Overview
Product Overview Hanging bracket Back Panel A Safety attachment Fuse holder point Power in Power out DMX in Back Panel B DMX out Microphone DIP switches Microphone sensitivity adjustment knob 2. Introduction Rev. 2... -
Page 6: Setup
Mounting Orientation The Trident™ may be mounted in any safe position, provided there is adequate room for ventilation. Rigging Be sure that the structure can support the weight of the fixture. Mount the product securely. This may be done with a screw, nut and bolt, or a hanging clamp. Be sure to also use a safety cable. The hole in each bracket is 13 mm in size. -
Page 7: Operating Instructions
DMX channel 100, will read data from channels: 100, 101, 102, 103, 104, 105 and 106. Choose the starting addresses for each fixture so that the channels used do not overlap. In addition, you should note the starting address selected for future reference. The Trident™ fixture uses 3 DMX channels. -
Page 8: Custom Program
Custom Program This fixture has individual control over each of the following functions via DIP switches: color, strobe, and motor rotation. These functions may be combined in any combination. Please see the instructions below for further explanation. Plug the fixture into power. Turn DIP switches [8] ~ [10] to the OFF position. -
Page 9: Appendix
5. A PPENDIX General Maintenance To maintain optimum performance and minimize wear, fixtures should be cleaned frequently. Usage and environment are contributing factors in determining frequency. As a general rule, fixtures should be cleaned at least twice a month. Dust build up reduces light output performance and can cause overheating. This can lead to reduced lamp life and increased mechanical wear. -
Page 10: General Troubleshooting
Install an optically coupled DMX splitter after unit #32 Interference from AC wires Keep DMX cables separated from power cables or black lights If you still have a problem after trying the above solutions, please contact CHAUVET® Technical Support. 5. Appendix Rev. 2... -
Page 11: Returns
Package must be clearly labeled with a Return Merchandize Authorization Number (RMA #). Products returned without the RMA # will be refused. Call CHAUVET® and request an RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 12: Technical Specifications
Data pin configuration ................pin 1 shield, pin 2 (-), pin 3 (+) Protocols ........................DMX-512 USITT DMX Channels ............................ 3 ORDERING INFORMATION Trident™ ..........................TRIDENT WARRANTY INFORMATION Warranty ......................2-year limited warranty Contact Us W o r l d W i d e...
