Driver Status Data
Port 3 Status Data
Status Register
13030
13031
13032
13033
13034
13035
13036
13037 to 13039
If the module is configured correctly, the configuration error word should have a
value of zero. Any other value indicates a configuration error. Use the value in
the configuration error word to determine which set of parameters are invalid in
the driver configuration area. The following table lists the bits associated with
each configuration error in the word:
Bit Code
0 0x0001
1 0x0002
2 0x0004
3 0x0008
4 0x0010
5 0x0020
6 0x0040
7 0x0080
8 0x0100
9 0x0200
10 0x0400
11 0x0800
12 0x1000
ProSoft Technology, Inc.
July 7, 2008
Description
Receive State:
-1 = Listening for data
1 = Receiving Port Data
2 = Waiting for Backplane transfer
Receive character count
Receive message count
Transmit State:
0 = Waiting for Data to Send
1 = RTS On
2 = RTS Timeout
3 = Sending data
4 = Waiting for RTS Off
5 = RTS turned off
30 = Intercharacter Delay
31 = Intercharacter Delay
32 = Intercharacter Delay
100 = Message Delay before Transmit
101 = Message Delay before Transmit
Transmit character count
Transmit message count
Configuration error word
No Valid Data
Description
Invalid selection for enabled parameter
Invalid Rx DB Start parameter
Invalid Tx DB Start parameter
Invalid Baud Rate
Invalid Parity (N, O, E, M or S)
Invalid Data bits (5 to 8)
Invalid Stop bits (1 or 2)
Invalid Handshaking parameter (N, Y, D or X)
Invalid Rx Termination Type
Invalid Rx Term Count value
Invalid Rx Timeout
Invalid Rx Delay
Invalid Rx Packet Length
