ProSoft Technology ProLinx ASCII Driver Manual page 26

ASCII ♦ ProLinx Standalone
Generic ASCII Serial Communication Module
Status Register
13013
13014
13015
13016
13017 to 13019
Port 2 Status Data
Status Register
13020
13021
13022
13023
13024
13025
13026
13027 to 13029
Page 26 of 40
Description
Transmit State:
0 = Waiting for Data to Send
1 = RTS On
2 = RTS Timeout
3 = Sending data
4 = Waiting for RTS Off
5 = RTS turned off
30 = Intercharacter Delay
31 = Intercharacter Delay
32 = Intercharacter Delay
100 = Message Delay before Transmit
101 = Message Delay before Transmit
Transmit character count
Transmit message count
Configuration error word
No Valid Data
Description
Receive State:
-1 = Listening for data
1 = Receiving Port Data
2 = Waiting for Backplane transfer
Receive character count
Receive message count
Transmit State:
0 = Waiting for Data to Send
1 = RTS On
2 = RTS Timeout
3 = Sending data
4 = Waiting for RTS Off
5 = RTS turned off
30 = Intercharacter Delay
31 = Intercharacter Delay
32 = Intercharacter Delay
100 = Message Delay before Transmit
101 = Message Delay before Transmit
Transmit character count
Transmit message count
Configuration error word
No Valid Data
Driver Status Data
