ASCII Protocol Configuration
4
ASCII Protocol Configuration
In This Chapter
[ASCII Port 0] ........................................................................................ 19
In order for the ASCII driver to function, a minimum amount of configuration data
must be transferred to the module from the module's file system. Care must be
taken in constructing the module configuration parameters. If the module does
not function as expected, examine the configuration file using the Debugger Port
on the module. All configuration parameters for the driver are found under the
[ASCII Port x] section. The x in the section name will have a value of 0 to 3
corresponding to the appropriate ASCII port.
After setting up the configuration file, download it to the module using ProSoft
Configuration Builder.
4.1
[ASCII Port 0]
[ASCII PORT 0]
Enabled
RS Interface
Rx DB Start
Tx DB Start
Baud Rate
Parity
Data Bits
Stop Bits
RTS On
RTS Off
Handshaking
Rx Termination Type: 1
Rx Term Count
Rx Term Chars
Rx Packet Length
Rx Timeout
Rx Delay
Swap Rx Data Bytes : N
Tx Timeout
Tx Minimum Delay
Swap Tx Data Bytes : N
4.1.1 Enabled
Yes or No
This flag specifies if the port on the module will be utilized. If the parameter is set
to No, the port will not be used. If the parameter is set to Yes, the port will be
used supporting the ASCII protocol.
ProSoft Technology, Inc.
July 7, 2008
: Y
#
: 0
#0=RS-232, 1=RS-485, 2=RS-422
: 200
: 0
: 19200
: N
#The coded values are as follows: N=None, O=Odd,
# E=Even, M=Mark and S=Space."
: 8
#Valid entries for this field are 5, 6, 7 and 8."
: 1
: 0
: 0
: N
#Handshake code of N, Y, D, X"
: 1
: 13 11 12 14 15 16 17 255 255 0 0 0
: 10
: 5000
: 1000
: 5000
: 0
ASCII ♦ ProLinx Standalone
Generic ASCII Serial Communication Module
Page 19 of 40
