User Manual
CBX-1 / CBX-2

6.2 Displayed Error Messages

Note: Error messages will only be displayed on handsets with a
display!
The display reads HOT.
Cause
The CBX control box is equipped with
duty cycle monitoring. If the predefined
on-time is exceeded, this protection
mechanism gets activated (refer to
chapter 4.3.5).
The display reads E + a error code.
Cause
An internal error occured.
Code
00 No error
01 Relay of motor 1 is stuck
02 Relay of motor 2 is stuck
03 Relay of motor 3 is stuck
04 Relay of motor 4 is stuck
05 Relay of motor 5 is stuck
06 Mosfet of motor 1 defective
07 Mosfet of motor 2 defective
08 Mosfet of motor 3 defective
09 Mosfet of motor 4 defective
10 Mosfet of motor 5 defective
11 Motor 1 socket shorted
12 Motor 2 socket shorted
13 Motor 3 socket shorted
14 Motor 4 socket shorted
15 Motor 5 socket shorted
16 Motor 1 socket plug detection
17 Motor 2 socket plug detection
18 Motor 3 socket plug detection
19 Motor 4 socket plug detection
20 Motor 5 socket plug detection
21 Oscillator defective
Description
Page 25/29
Solution
Wait until the control box has cooled
down and the displyed HOT goes out.
Then, the control box is ready for use
again.
Solution
Proceed according to the following error
list:
Solution
Unplug the control box. Contact our
customer service.
Unplug the control box. Contact our
customer service.
Unplug the control box.
Eliminate the external short-circuit.
Put the control box into operation again.
Connect a motor to the corresponding
motor socket.
Contact our customer service.
