User Manual
CBX-1 / CBX-2
3.2.1. Initial Operation Procedure
For initial operation of the control box proceed as follows:
3.2.1.1. Connect Drives
Connect the drive cables to the corresponding 8-pin DIN sockets (M1, M2).
Note: When connecting, strictly stick to the sequence M1, M2!
3.2.1.2. Connect Handset
Connect the handset to the 7-pin DIN socket (HS).
Note: You may use various LOGICDATA handsets with th CBX control
box! For detailed information refer to chapter „Optional Products" (page
xx).
3.2.1.3. Connect Optional Components
If you want to use a squeeze line, you can connect it through the optional module
(ACS-CB-PINCH) to the CBX control box.
3.2.1.4. Connect Mains Supply
Caution: Check prior to connecting the mains supply cable,
• whether the mains supply voltage is 110V/60Hz,
• whether all components are connected to the correct interfaces,
When the power cord is connected, the CBX control box is operational!
Page 11/29
