User Manual
CBX-1 / CBX-2
4.4.2. ACS-CB-PINCH mounting and connection
Caution: Unplug the power cord when connecting the ACS-CB-PINCH
module!
To install and connect the ACS-CB-PINCH module, proceed as follows:
1. Connect the short cable (interface
(M1 or M2).
2. Connect the cable of the drive to the interface
3. Mount the module with 2 screws in the holes on the bottom side of the desk top.
4. Connect the squeeze line to the interface
line is already mounted to the bottom side of the desk top).
5. Connect the power cord to the outlet. Now the squeeze line is operational.
Abb. 5 – Connecting the pinch protection module
Interface to connect the CBX control box to the ACS-CB-PINCH module
Interface to connect the squeeze line to the ACS-CB-PINCH module
Interface to drive 1 or 2 (M1 oder M2)
Squeeze line mounted to the height adjustable desk
CBX control box
) to the desired interface of the control box
of the module.
of the module (assuming the squeeze
Page 21/29
