If you have a problem, question, or request, call
your local dealer, or Steelcase Line 1 at
888.STEELCASE (888.783.3522)
for immediate action by people who want to help you.
(Outside the U.S.A., Canada, Mexico, Puerto Rico,
and the U.S. Virgin Islands, call: 1.616.247.2500)
Or visit our website: www.steelcase.com
©
2009 Steelcase Inc.
Grand Rapids, MI 49501
U.S.A.
Printed in U.S.A.
Support Plates (pages 3, 4 and 7)
Legs (page 8)
Cantilevers (pages 4, 5, 6 and 7)
™
ap40
Worksurface, Supports & Legs
Side Support Brackets (pages 3 and 4)
Reinforcement Brace (page 8)
#2 Square Drive Bit
#2 Phillips Drive Bit
Bit Holder
Page 1 of 8
939500519 Rev B
Advertisement
Table of Contents
Related Manuals for Steelcase ap40
Summary of Contents for Steelcase ap40
- Page 1 Reinforcement Brace (page 8) Bit Holder If you have a problem, question, or request, call your local dealer, or Steelcase Line 1 at 888.STEELCASE (888.783.3522) for immediate action by people who want to help you. (Outside the U.S.A., Canada, Mexico, Puerto Rico, and the U.S.
- Page 2 ® Cable Management Gaps NO GAP NO GAP NO GAP NO GAP NO GAP NO GAP NO GAP Page 2 of 8 939500519 Rev B...
- Page 3 ® Mounting Worksurfaces TIP: Scallop covers must be handled Attaching Adjoining Worksurfaces with care to avoid damage. Using the with Support Plates scallops as a handhold is not Mark height of worksurfaces to 27-1/2". Attach recommended. Replacement scallop Place support plates as shown. Secure a screw in the support brackets to the vertical junctions.
- Page 4 ® Typical Panel-Mounted Applications Page 4 of 8 939500519 Rev B...
- Page 5 Cantilever to be used on Avenir panels. "9" IDENTIFICATION HERE: Cantilever to be used on Mounting Bracket Identification Series 9000 and ap40 panels. Using the proper cantilever 4 SLOTS 3 SLOTS will put the worksurface at the same height as the older cantilever versions.
- Page 6 (1a). Tap into position with a mallet (1b). NOTE: The tab shown in the close-up (1c) provides 1/2" spacing on the panels. Remove this tab when used on ap40 panels. Tip mounting plate and insert tab through the cantilever for left, right or shared conditions.
- Page 7 ® Mounting On-Module Cantilevers Lower worksurface (4a) and attach using four (4) #10-10 x 1" pan head screws for left hand or right hand cantilevers and seven (7) #10-10 x 1" pan head screws for the shared cantilever (4b). Attach the tie strap using four (4) #8-11 x 7/8"...
- Page 8 ® Attaching Worksurface Reinforcement Brace For worksurfaces without legs, measure 6" in from the front edge of the worksurface on its bottom side. For worksurfaces with legs, measure 7-1/2" from the front edge. Use the support brace as a straight edge. Center the 57"...
