7.
Position and loosely secure cover to vertical support.
8.
Align transition worksurface with adjacent worksurfaces and tighten all screws and bolts. Now press cover
hinge into embossed tabs on vertical support.
9.
Secure ports onto vertical support. Insert rear port corner,and snap port covers into place.
Assembly Directions
93-9503977 REV C
REAR PORT
COVER
SCREW .312-18
(2) REQ'D
PORT
VERTICAL
SUPPORT
COVER
PORT
COVER
VERTICAL
SUPPORT
Page
4 of 4
