- Page 1 Workrite Sequoia Assembly Instructions for Model SQ-202 #1500202 - Rev A...
- Page 2 Verify that you have all the hardware and tools needed for the assembly. Check your packages against the parts list above to verify that you have all the parts needed. You will also need the following tools: #3 tip Phillips screwdriver Workrite Ergonomics 800.959.9675 www.workriteergo.com...
- Page 3 2.5mm Hex Wrench (I) Install Cable Manager (B) onto the Pole and slide down to the bottom. Place Collar (C) onto the pole about 6” up from the bottom and install Set Screw (G) and tighten securely. Workrite Ergonomics 800.959.9675 www.workriteergo.com...
- Page 4 Outer Monitor Mount: Align the outer mounts (K) to the VESA pattern in the monitors. Install 4 VESA Mount Screws (H) in each monitor and tighten securely with a #2 Phillips screwdriver. Workrite Ergonomics 800.959.9675 www.workriteergo.com...
- Page 5 Note: During assembly it may become necessary to adjust the width of the outer monitors to adjust for curved alignment and minimize gaps between monitors. To do this simply loosen, move, and retighten the Mount Knob (F) to the wing bars. Workrite Ergonomics 800.959.9675 www.workriteergo.com...
- Page 6 Arc Adjustment +/- 10° Horizontal Adjustment Vertical Adjustment with with VESA Mount Knob Ratchet Lever & Collar Guide monitor and power cables over and around Ratchet Levers and Wing Knobs then through the Cable Manager (B). Workrite Ergonomics 800.959.9675 www.workriteergo.com...
