Workrite Ergonomics Conform Sit-to-Stand Arm Assembly/Installation Instructions

Assembly & Installation Instructions:
Conform Sit-to-Stand Arm CONF-STS-WOPB-S

Parts Included

A
14" Pole with
HD Base
Qty: 1
CONF-PB-14HDCCG-S

Tools Supplied

H I
M2.5 Allen wrench
Qty: 1
1

HD Base C-Clamp Installation

Note: If you are installing using a grommet, skip to Step 2.
1.1 Using C-Clamp handle, loosen the C-Clamp on the Pole Base (A) wide enough
to fit over the edge of the worksurface.
1.2 For thinner tops: Adjust the C-Clamp lower plate if it is too wide to fit over
the edge of the worksurface. To adjust, remove the screws using the 5 mm
Allen wrench (J). Slide the C-Clamp lower plate to the upper screw holes,
replace the screws and tighten until secure.
1.3 Remove Adhesive Pad (B) backing. Apply the pad to the bottom surface of
the base, adhesive side up, so that it aligns with the front edge of the base
and sticks in place.
1.4 Place C-Clamp over the rear edge of the worksurface and tighten the clamp
by turning the C-Clamp Bolt until secure.
Skip to Step 3.
B
1 of 4
D
B
Adhesive Pads
Qty: 1
C
Grommet Bolt, Wing
Nut & M8 Steel Washer
Qty: 1
J
M4 Allen wrench
Qty: 1
A
1.3
Loosen
U-Bracket
Qty: 1
E
Single Pole Adaptor
Qty: 1
Monitor Hardware
K
M5 Allen wrench
Qty: 1
L
1.4
Tighten
Workrite Ergonomics | 800.959.9675 www.workriteergo.com
F
Conform Sit-Stand
Articulating Arm
Qty: 1
G
Pivot Cover Cap
Qty: 1
Monitor Screws, Medium
Qty: 4
Monitor Screws, Short
Qty: 4
A
Tighten
1.1
Loosen
J
1.2
For thinner tops
