LINDR PYGMY 30/K profi Instruction Manual page 10

12.3 Connection and Pressurisation by Built-In Compressor (Two-Tap Device)
1. Beverage inlet
2. Air outlet
3. Keg coupler (A-system, S-system, M-system)
4. F 5/8 x 9.5 mm speed tting
10 a
gure
6.
4.
5.
10
Only for PYGMY 30/K pro models with built-in air compressor and GREEN LINE models PYG-
MY 20/ K, PYGMY 25/ K, KONTAKT 40/K, KONTAKT 70/ K, KONTAKT 155/ K.
The air mini-compressor is built into the cooling device itself. Automatic pressure regulation
is set to 2.8-3.2 bar. K pro models allow smooth pressure regulation in 1.0-3.4 bar range. The
set pressure will be displayed on the pressure gauge in bars. The compressor can be turned
o separately with a switch. The air outlet from the cooler terminates in a 5/16" (8 mm) speed
tting marked AIR. The air compressor is zero-maintenance, tted with a molecule lter for
3.
3.
4.
5.
7.
Built-In Air Compressor
the drawn-in air.
5. F 5/8 x 8 mm speed tting
6. Y 8 x 8 x 8 mm speed tting
7. Beverage
8. Compressor switch
8.
2.
1.
