- Page 1 TIB SERIES Battery Operated Paddle Wheel Flow Meter TIB SERIES INSTRUCTION MANUAL Read the User's Manual Carefully. Manufacturer Reserves the Right to Implement Changes Without Prior Notice.
-
Page 3: Safety Information
Personal Protective Equipment (PPE) Always utilize the most appropriate PPE during installation and service of Truflo products. Pressurized System Warning WARNING! Sensor may be under pressure, take caution to vent system prior to installation or removal. Failure to do so may result in equipment damage and/or serious injury. -
Page 4: Installation
TIB SERIES Battery Operated Paddle Wheel Flow Meter Installation Very Important TIB Series Lubricate O-rings with a Viscous Lubricant Compatible Screw Down Retention Cap Positioning Tab with the Materials of Construction. Ensure O-Rings are well Greased Using an Alternating | Twisting Motion Carefully Lower Lubricate (Grease) the Sensor into the Fitting. -
Page 5: Installation Positions
TIB SERIES Battery Operated Paddle Wheel Flow Meter Correct Sensor Positioning Series Flow Meters measure liquids only. No air bubbles should be present the pipe must always be full. The sensors are not effective in laminar or transitional flow applications. Minimum Reynolds number required is 4500. - Page 6 Battery Operated Paddle Wheel Flow Meter Long Service Life Maximum Pressure | Temperature The TIB Series is equipped with a Zirconium Ceramic Rotor Pin Note: During system design the specifications of and 2 Bushings. The TIB Series also incorporates a contoured, all components must be considered.
- Page 7 TIB SERIES Battery Operated Paddle Wheel Flow Meter Press for Increase Value & Press for Decrease Value Programming Press to Save Value Press to Change Digit RANGE STEPS DISPLAY OPERATION Step-1 Home Screen Current Flow Rate | Total Press &...
-
Page 8: Battery Replacement Procedure
TIB SERIES Battery Operated Paddle Wheel Flow Meter Battery Replacement Procedure... - Page 9 TIB SERIES Battery Operated Paddle Wheel Flow Meter Rotor Pin | Paddle Replacement Procedure GENTLY tap pin with Tap until Rotor is 50% out Line up Pin with Rotor Hole Mallet or Hammer Small Pin Rotor Hole Pull out Rotor Pin...
-
Page 10: Min | Max | Flow Rates
Form and Flow Meter. must be returned to Icon Process Controls directly or to the authorized distributor. Product returned without a RGA number and Service Form will not be warranty replaced or repaired. Truflo Flow Meters are warranted out of box but not against any damage, due to Process or Misapplication Failures e.g. High Temperature,... - Page 11 TIB SERIES Battery Operated Paddle Wheel Flow Meter TI Series Products • Industry's Highest Accuracy: ±0.50% • PVC | PP | PVDF • Retrofits into Signet® Fittings • Size Range - ½" - 24" • Low Pressure Drop • Password Protected Security •...
