Using The Display - Casio CTK-496 User Manual

General Guide

Using the Display

1
11
10
1.
An indicator appears next to the type of setting you are currently performing (TONE, RHYTHM, SONG BANK).
2.
Tone number, rhythm number, song number, keyboard settings value
3.
Rhythm, auto-accompaniment, Song Bank tune beats
4.
Tone name, rhythm name, song name, mode name, keyboard settings name
5.
Musical staff representation of notes and chords you play on the keyboard. A pedal indicator (
pedal is depressed. An octave indicator (
actual notation is one octave higher than that shown on display.
6.
Uses a graphic keyboard to show notes and chords played on the keyboard or played during Song Bank tune playback
7.
Auto-accompaniment, Song Bank, chord book chord names
8.
Dots indicate fingerings during Song Bank playback. "L" and "R" indicate left-hand and right-hand parts.
9.
Rhythm, auto-accompaniment, Song Bank tune tempo
10.
Rhythm, auto-accompaniment, Song Bank tune tempo; volume setting
11.
Song Bank controller indicators
NOTE
• Display examples shown in this User's Guide are intended for illustrative purposes only. The actual text and values that
appear on the display may differ from the examples shown in this User's Guide.
E-10
2 3 4
8
9
) appears when you play notes in the range from C 6 to C7 to indicate that their
5
7
• This is how the display appears
while the Song Bank is in use.
) appears when the keyboard's
6
627A-E-012A
