  • Page 1 SERVICE MANUAL SERVICE MANUAL SERVICE MANUAL SERVICE MANUAL SERVICE MANUAL SEGA AMUSEMENTS EUROPE LTD. IMPORTANT 42 Barwell Business Park, Leatherhead Road, Chessington, SURREY. United Kingdom KT9 2NY • Before using this product, read this manual carefully to understand the contents herein stated.
  • Page 2 USER MANUAL This manual is suitable for use in Territories listed below : U.S.A. Europe Asia - 1 -...

  • Page 3: Table Of Contents

    [Table of Contents] Simple Facts About The Machine ……………………………………………………3 Introduction ......................... 4 Simple Maintenance & Servicing ……………………………………………………5 Test & Service ………………………………………………………………………..5 Machine Installation ………………………………………………………………….6 Games Descriptions ………………………………………………………………….6 Getting Started / How To Play ……………………………………………………….6 Test Menu…… ……………………………………………………………………..7 System Information …………………………………………………………………..8 Test Input …………………………………………………………………………..9 Output Test…………………………………………………………………………..10 Coin Test………………………………………………………………………………11...

  • Page 4: Simple Facts About The Machine

    Simple Facts About The Machine Machine Name : PIGS MIGHT FLY Machine overall dimension : H1950mm x W760mm x L750mm Machine Weight :160kg Voltage : 120V, 2.2A, 60Hz for US : 230V, 1.3A, 50 Hz for the UK : for other countries, voltage depend on individual countries. Power Consumption : 264W for US 299W for UK LCD dimension : Standard 37 inches.

  • Page 5: Introduction

    Introduction This manual describes the information on handling and maintenance of PGIS MIGHT FLY manufactured by VS Electronic Assembly (Zhuhai) Co. Ltd. (authorized by SEGA SAMMY GROUP Japan). The machine must not be used for other improper purposes. Any adjustment procedures and maintenance service must be performed by a qualified engineer or technicians who are comprehensively understands the machine.

  • Page 6: Simple Maintenance & Servicing

    Volume Control button : Adjust volume/sound of the games. Call the below phone number for further assistance: 1. USA : SEGA AMUSEMENTS USA INC. Arthur Avenue, Elk Grove Village, IL 60007-5215, USA Tel : +1-847-364-9787 , +81-888-877-2669 (Toll Free) Fax : +1-847-427-1065 2.

  • Page 7: Machine Installation

    Machine Installation The installation is simple. Follow the below procedures: 1. Lower down the M16 bolt (at the bottom of the machine) so that the whole machine sit firmly on the floor. 2. Connect the AC inlet with the cable provided to the power supply. Switch on the machine. The on-off button is located at the AC inlet (rear bottom).

  • Page 8: Test Menu

    In game there are tiers of UFOs with different ticket values and Pigeons that fly across the screen to obstruct the Pig‟s flight. At the top of the screen there is one Mother ship, which hitting will win the Super Bonus. The Super Bonus value is dependant on the Game Settings.

  • Page 9: System Information

    If the cursor is moved past the EXIT option, it will reappear at the top of the menu list. Selecting EXIT will terminate the test routine menu and launch the current game application. System Information The System Information Test lists the revision numbers and names of currently installed system components.

  • Page 10: Test Input

    Game Version Version number of currently installed game IO Board Version Version number of IO Board being used Security Key Type of Security Key installed Input Test This Test is used to test the „System Inputs‟ such as Seesaw Trigger and Start Button. To implement the test, Operate each device listed and check the results on screen.

  • Page 11: Output Test

    VTS. Service Button ON = Pressed, OFF = Not Pressed. Test Button ON = Pressed, OFF = Not Pressed. EXIT Press the TEST and SERVICE buttons simultaneously to EXIT Output Test This Test is used to check System Output such as Lamps and Ticket Use the Service Button to move the cursor to the desired test item.

  • Page 12: Coin Test

    Start Lamp ON = Lamp ON, OFF = Lamp OFF Ticket Vend ON = Tickets Vend, OFF = Tickets do NOT Vend Ticket Meter Ticket Meter increase by 1 each ON/OFF cycle Coin Test Coin Count Coin Count value from IO Board Credits Total number of Coin credits added to the system Service Credits...

  • Page 13: Sound Test

    Sound Test This Test is used to set Audio Levels for the Game and Test the function of the Speakers. Attract Music ON = Sound will be played in the Attract mode OFF = No sound in Attract mode Play Music ON = A test audio sample will be played OFF = Test audio sample is turned off Play Effect...

  • Page 14: Screen Test

    Screen Test This Test is used to display various test patterns for the display screen. Colour Bars Displays vertical colour bars for colour balance correction Brightness Displays graduated greyscale for brightness adjustment Grid Alignment Displays grid for screen size alignment - 13 -...

  • Page 15: Bookkeeping

    Bookkeeping This Test displays the bookkeeping meters, it consists of 3 pages. Bookkeeping Page 1 Total Plays Total number of games played Average Game Time Average time in milliseconds per game Credits In Total number of coin credits inserted Service Credits In Total number of service credits inserted Tickets Out Total number of tickets dispensed...
  • Page 16 Use the Service button to navigate, and the Test button to action changes of the following options Clear Bookkeeping Clears all Bookkeeping data Next Page Shows Bookkeeping Page 2 Bookkeeping Page 2 Plays On Sunday Total number of plays on a Sunday Plays On Monday Total number of plays on a Monday Plays On Tuesday...
  • Page 17 Use the Service button to navigate, and the Test button to action changes of the following options Next Page Shows Bookkeeping Page 3 Bookkeeping Page 3 This Test displays a total of games, broken down into hours a day. Each hour is logged separately in 24 hour format therefore 00-01 logs games between 12am and 1am 01-02 logs games between 1am and 2am and so on...

  • Page 18: Clock Setting

    Clock Setting This Test is used to set the PC‟s real time clock facility Use the Service button to navigate, and the Test button to action changes to the follow options. * “Current Time” and “Current Date” can not be selected and change after changing the below options Current Time Current time in 24 hour format HH:MM:SS...

  • Page 19: Games Setting

    Minutes 00 to 59 – Minutes setting Seconds 00 to 59 – Seconds settings Game Settings This Test is used to set various game parameters. Use the Service Button to navigate, and the Test to action changes to the following options.
  • Page 20 the option chosen. E.g. Super Bonus Add set to “2” each play the Super Bonus will increase by 2. Options: *None, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10 *Setting Super Bonus Add to “None” will turn off this mode and the value of Super Bonus Base value is used Super Bonus Limit Set the maximum amount of tickets to be paid out when...

  • Page 21: Payout Setting

    Payout Settings This Test is used to set ticket Payout parameters. Payout In Freeplay Enables/Disables ticket payout in Freeplay Options: ON = Tickets in Freeplay will be awarded OFF = Tickets in Freeplay will NOT be awarded *Default setting for this should be OFF Value Of Play This setting should be the same as the Credit Board.
  • Page 22 change the Credit Board settings. Please note changing the Credit Board setting WILL NOT change VALUE OF PLAY settings, or vice versa. Options: 0.01, 0.02, 0.05, 0.10, 0.20, 0.25, 0.30, 0.50, 1.00, 2.00 Value Of Ticket This sets the cash value of 1 ticket. Options: 0.01, 0.02, 0.03, 0.04, 0.05, 0.06, 0.07, 0.08, 0.09, 0.10, 0.20, 0.25, 0.50, 1.00, 2.00 Aiming Percentage...

  • Page 23: Wiring Diagram

    Wiring Diagram - 22 -...
  • Page 24 - 23 -...

  • Page 25: Design Related Part

    Design Related Parts UB-1022UK UB-1302UK UB-1022UK UB-1028UK (RIGHT) UB-1028UK (Right) UB-1028UK (Left) UB-2007UK UB-2001UK UB-1026UK (Right) UB-1022UK UB-1025UK (Left) - 24 -...

  • Page 26: Part List

    Part List ASSEMBLY NUMBER ASSEMBLY NAME QUANTITY UB-1001UK ASSY MAIN CABINET UB-1001-01-DUK ASSY DOOR FRONT 610-9500UK-01 ASSY COIN BOX DOOR UB-1150UK ASSY INPUT SWITCH UB-2500UK ASSY CONTROLLER UB-1019-01UK MICROSWITCH ASSY UB-2001UK PLATE CTRL PNL UB-2007-01UK START BUTTON ASSY UB-1400UK ASSY DISPLAY 200-6037-LGP ASSY LCD LGP UB-1006-01UK...
  • Page 27 UB-1007-01UK UB-1300UK-01 UB-1350UK-01 200-60370LGP UB-1028UK (RIGHT) UB-1006-01UK UB-2007-01UK UB-1150UK UB-101-01-DUK UB-1001UK 610-9500UK-01 - 26 -...
  • Page 28 UB-1001-01-CUK UB-1028UK (RIGHT) UB-1028UK (IN BACK SIDE) - 27 -...
