- Page 1 USER'S MANUAL CRANE MACHINE Cubic 4 Catcher MANUAL VERSION：F12H-SAJ-E-VB1.0 F12H-M01E ISSUE DATE：2019.10.16 頁...
-
Page 2: Table Of Contents
CONTENTS SAFETY NOTICE ....................3 1 SAFETY NOTICE ......................3 2 TRANSPORTATION AND MOVING ................3 3 POWER NOTICE ......................3 4 ORDER IN POWER ON ....................3 5 ORDER IN POWER OFF ..................... 3 ABOUT THE MACHINE .................. 4 1 SPECIFICATION ...................... -
Page 3: Safety Notice
SAFETY NOTICE 1 SAFETY NOTICE a. Please read carefully with enclosure of “Warranty”. b. Please read carefully with enclosure of “Maintenance”. c. Please check and maintain the machine regularly, DO NOT use any synthetic detergents to clean the machine. d. Places where the ground is sloping, uneven or there is strong vibration. e. -
Page 4: About The Machine
ABOUT THE MACHINE 1 SPECIFICATION a. Voltage & Frequency AC100V (50 / 60 Hz) b. Dimension (W) 1217 x (D) 1217 x (H) 985 mm c. Weight 155 kg d. User 4 people e. Environment Weather Protected Environment f. Temperature 0°C~40°C g. -
Page 5: List Of Components
3 LIST OF COMPONENTS ④ ① ② ③ Maual ⑤ ⑥ ⑦ SEGA NO. Q / U FEILOLI NO. SEGA PART NAME SPEC CASH KEY 8460 TSBF A01C000248A A01-C000248A FRONT KEY 3123 TSBF A01C000073A A01-C000073A PLUG FORM ACCORDING AREA. TSBF A01G000203A... -
Page 6: Setting
SETTING 1 System Setting ➢ Electronic Counter ① ③ RESERVED (NO USE) RESERVED (NO USE) A：Coin Mech 1 Counter B：Reserved C：Prize Counter ④ FREE PLAY ② SETTING ➢ Maintenance Tray Select Setting Item Exit the Item Enter the Item Confirm and save Select Setting Joystick... -
Page 7: To Enter Setting Menu
SETTING 2 To Enter Setting Menu： (1) When the machine is in stand-by mode, enter SETTING button to enter setting menu. (2) 6 main setting items in setting menu : >>A : Setting >>B : Clamp Power >>C : Accounts >>D : Auto Play >>E : Motor Speed >>F : Test... - Page 8 > A1 : Coin-> Credit : A1 : Coin->Credit >> Coin->Credit >>Coin Bonus Joystick : UP or DOWN - select items. RIGHT - enter the item. LEFT - Exit > A11 : Coin-> Credit : Coin->Credit →Next ↑: + ↓:- 1~10 Coin(s) = = 1~10 Credit(s) COIN :...
- Page 9 A3 : Win rate : （The explanation below is for winning once per 100 games. Only valid for games by inserting coins） 。 A3 : Win rate →Next ↑:+ ↓:- = 100 >>MODE: Random / Fixed Joystick [Up] / [Down]→ Adjust value Joystick [Right] / [Left]→...
- Page 10 A6：Coin Save： A6 : Coin Save ☼ ->Exit ↑↓:Change =Save / Clear Joystick[Up]/ [Down]→ Change setting. Save：Save inserted coins (credits) Clear: Coins (credits) will be reset when reboot [CATCH]→ Save & Exit. A7：Play Till Win： A7 : Play Till Win ☼...
- Page 11 >B : Clamp Power : Claw Catching Voltage >>B1 : Strong-V >>B2 : Weak-V >>B3 : UP- Height B2 : Hold Weak-V Low voltage remains for catching: The voltage remains when claw is reached top and moving to prize output hole. B3 : Pick up - Height High voltage is getting lower to low voltage as claw is rising.
- Page 12 B1 : Strong-V：(High voltage for catching) B1 : Strong-V 20.0V ~ 48.0V ☼→Exit ↑:+ ↓ :- = 48.0V Joystick [Up]/ [ Down]→ Change setting Range: 20V~48V [CATCH] ☼→ Save & Exit It will save the setting and exit automatically if operator doesn’t change anything for 30 seconds.
- Page 13 > C : Accounts(アカウント) : C : Accounts C1>Win Rate Bank C2>CoinPlay Cou.(counter) C3>Gift Out Cou. (counter) C4>Reset All Data C1：C1:Win Rate Bank : （example : 0） 。 C1 : Win Rate Bank Counter “0”= push ☼-> 2 sec Win Rate Bank：the value increase 1 for every play by inserting coins, and will be reset after winning Joystick →...
- Page 14 C3：Gift Out counter : （Prize payout counts） （value 17 is as the explanation） 。 C3 : Gift Out Cou. (counter) Counter = 17 Joystick → No use. Press [CATCH] once → Return to Accounts MENU. C4：Reset All Data : C4 : Reset All Data >>No -->Exit >>Yes -->Save Joystick [Up] / [Down]→...
- Page 15 3. >E：Motor Speed Adjustment : >E : Motor Speed E1>Forward Speed E2>Backward Sp.(Speed) E3>Left Speed E4>Right Speed E5>Down Speed E6>Up Speed E7> ALL Speed Joystick [Up] / [Down]→ Select items Joystick [Right → Enter Joystick [Left]→ Exit E1：Forward Speed E1 Forward Speed ☼→Test ↑:+ ↓...
- Page 16 E2：Backward Speed E2 Backward Sp.(Speed) ☼→Test ↑:+ ↓ :- = 50% Joystick [Up] / [Down]→ Adjust value. (Range : 30%~60%, change the value by per 10%) 30%：Slowest 60%：Fastest [CATCH]→ Save & Enter to test mode Test mode： E2 Backward Sp.(Speed) >>Joystick Test = 50% Test Joystick [Up] / [Down]→...
- Page 17 E4：Right Speed E4 Right Speed ☼→Test ↑:+ ↓ :- = 50% Joystick [Up] / [Down]→ Adjust value. (Range : 30%~60%, change the value by per 10%) 30%：Slowest 60%：Fastest [CATCH]→ Save & Enter to test mode Test mode： E4 Right Speed >>Joystick Test = 50% Test Joystick [Right] / [Left]→...
- Page 18 E6：Up Speed E6 Up Speed ☼→Test ↑:+ ↓ :- = 50% Joystick [Up] / [Down]→ Adjust value. (Range : 30%~60%, change the value by per 10%) 30%：Slowest 60%：Fastest [CATCH]→ Save & Enter to test mode Test mode： E6 Up Speed >>Joystick Test = 50% Test Joystick [Up] / [Down]→...
- Page 19 4. >F：Test F : Test >>F1 : Gift Sensor >>F2 : Coin Test Joystick [Up] / [Down]→ select items. Joystick [Right] → enter the item. Joystick [Left] → Return to MENU。 F1：Gift Sensor test Step 1： F1 Gift Sensor test >>Sensor VR Adj.
- Page 20 Step 2： F1 Gift Sensor test >>[CATCH]-->Exit LED=ON << OK >> (1) Check the LED is on. If not, it might be caused by wiring connection problem or sensor error. (2) Both step 1 and 2 should be all ok. F2：Coin Test >F2：Coin Test ~ Insert Coins ~...
-
Page 21: Link Main Pcb Setting
3 LINK MAIN PCB SETTING : Tilt Cubic Slave 1 Cubic Slave 2 Amplifier Cubic Master Cubic Slave 3 Cubic Slave 4 RGB LED Strip RGB LED Strip RGB LED Strip RGB LED Strip DIP-SW FUNCTION DEMO MUSIC DEMO MUSIC INTERVAL TIME ※Please reboot the machine when DIP switch setting has been changed. -
Page 22: Wire Harness Diagram
WIRE HARNESS DIAGRAM Joystick Cabinet Control Panel MAIN Electric Paned A&B 250 Terminal 187 Terminal T2.54-13P BOARD CATCH CATCH +12V Button SW Button Light NH2.5-5P RIGHT Forward +12V LEFT CATCH Button Light Back B Counter Input T2.54-7P Female Female Male Male Forward... - Page 23 Main PCB 1~4 Electric Panel A&B SM2.5 SM2.5 SM2.5 SM2.5 25P Male Socket Male Female Female Male F-W Motor L-R Motor U-D Motor Claw Power Forward SW Back SW Left SW Up SW Down SW Gantry Set SM2.5 SM2.5 Male Female Right SW F-W Motor...
- Page 24 RGB LED LIGHT - 1 RGB LED LIGHT - 2 RGB LED LIGHT - 3 RGB LED LIGHT - 4 SM2.5 Male SM2.5 Male SM2.5 Male SM2.5 Male SM2.5 Female SM2.5 Female SM2.5 Female SM2.5 Female Male -15P Black Male -15P Black Electric Panel A Electric Panel B Male...
- Page 25 Electric Panel A Stereo Male Female -4P Master Panel T3.96 2P Male 4P 236-3P Terminal Speaker Black Black T3.96 2P White JP16 Speaker Amplifier Black +12V T3.96 AC IN L FG Master Power Supply VH3.96-3P +12V +12V T2.54-2P Tilt WIRE HARNESS DIAGRAM...
- Page 26 AC Circuit Diagram Electric Panel Ａ AC IN 圖 Main Power Main Power Input VH3.96-8P Input6682 6682 Male-3P 1 Input 8 Output AC IN OUT Female-3P Terminal Board 1 Filter Light 1 L(White) 1 Input 8 Output -3P Green Yellow 6682 6682 N(Black)
-
Page 27: Troubleshooting
TROUBLESHOOTING 1 Error Code ERROR ITEM SOLUTION (1) Check wiring COIN COUNTER ERROR (2) Replace counter (1) Check wiring PRIZE COUNTER ERROR (2) Replace counter Check NC/NO SW on coin selector, COIN SELECTOR ERROR it should be NO (1) Adjust sensor VR PRIZE SENSOR ERROR (2) Replace sensor PCB DATA ERROR...
