- Page 1 ™ ’ AILEA WNER ANUAL...
-
Page 2: Table Of Contents
• This fan is designed to be installed on an existing electrical outlet box. The outlet box must be UL Listed for ceiling fan installations, if it is not, a new box must be installed. Casablanca extension poles are available for sloped or high ceiling installations. -
Page 3: Mounting Recommendations
MOUNTING RECOMMENDATIONS Before mounting your Casablanca fan, read the following helpful recommendations. The location of the fan, air circulation, and fan size are all important factors to consider before installation. Location Ceiling fans have practical uses in almost every room in your home. We suggest you follow these mount- ing recommendations as you decide where to install your Casablanca fan. -
Page 4: Preparation Instructions
PREPARATION INSTRUCTIONS Unpacking: Before assembling and installing your ceiling fan, remove all parts from the shipping cartons and check them against the parts listed here. Before discarding packaging material, be certain that all parts have been removed. ALLEN SET SCREW ⁄... -
Page 5: F An Inst Alla Tion
Installing a New Ceiling Fixture Outlet Box If you do not have an existing fixture located where you wish to place your Casablanca fan, an approved ceiling fixture outlet box must be installed and wired. Warning: To reduce the risk of fire, electrical shock,... - Page 6 Step 2. Thread the wires from the ceiling through the opening in the canopy. Attach the canopy to the crossbar mounting bracket with three of the 8-32 x 2 ″ long canopy screws and canopy lock washers. Using the screwdriver, tighten the screw firmly by hand only.
- Page 7 AILEA CANOPY HATCH INSTALLATION Step 6. Tuck the wires into the canopy with the wire nuts pointed upwards, so that the WHITE and BLACK wires are on opposite sides of the canopy and all wires are clear of the canopy opening. Step 7.
- Page 8 Step 10. On the motor remove the five shipping blocks by unscrewing the screws. Discard the five shipping blocks and screws. BLADE/BLADE HOLDER INSTALLATION Step 11. Install the assembled blade and blade holder to the fan motor. Use the blade holder screws provided.
- Page 9 AILEA Step 15. Install 2 of the 3 switch housing screws onto the fan adapter plate, leaving ⁄ " threads visible. Feed the wire connec- tor from the fan through the center of the switch housing. Align the 2 screws on the adapter plate with the keyhole slots of the switch housing.
-
Page 10: 3-Speed Opera Tion
SWITCH HOUSING TROUBLESHOOTING Never Lubricate this Fan! The precision motor at the heart of your Casablanca fan features sealed bearings that are lubricated for life. Do not attempt to oil the motor. Changing Light Bulbs Be sure to turn power to the fan OFF at the wall switch or circuit breaker before changing light bulbs. - Page 11 761 CORPORATE CENTER DRIVE • POMONA, CA 91768 TOLL FREE: 888-227-2178 www.CasablancaFanCo.com ©COPYRIGHT 2004 CASABLANCA FAN COMPANY • U.S. PATENT PENDING PRINTED IN CHINA...
