Summary of Contents for Casablanca Malibu Star
-
Page 2: Safety First
• This fan is designed to be installed on an existing electrical outlet box. The outlet box must be UL Listed for ceiling fan installations, if it is not, a new box must be installed. Casablanca extension poles are available for sloped or high ceiling installations. -
Page 3: Mounting Recommendations
MOUNTING RECOMMENDATIONS Before mounting your Casablanca fan, read the following helpful recommendations. The location of the fan, air circulation, and fan size are all important factors to consider before installation. Location Ceiling fans have practical uses in almost every room in your home. We suggest you follow these mount- ing recommendations as you decide where to install your Casablanca fan. -
Page 4: Installation Instructions
Installing a New Ceiling Fixture Outlet Box If you do not have an existing fixture located where you wish to place your Casablanca fan, an approved ceiling fixture outlet box must be installed and wired. Warning: To reduce the risk of fire, electrical shock,... -
Page 5: Crossbar Mounting Bracket Installation
ALIBU CROSSBAR MOUNTING BRACKET INSTALLATION Proceed with installation as follows: Step 1. Route the wires from the ceiling outlet box through the crossbar mounting bracket center hole. Attach the bracket, with ground wire and ridges down, to the ceiling fixture out- let box with the mounting hardware included with the outlet box. -
Page 6: Hanging The Fan
Step 3. To hang the fan body in the canopy, hold the fan body firmly and in- sert the ball into the canopy opening. Check that no wires were pinched. Ro- tate the fan body until the slot in the ball fits into the pin opposite the canopy opening. -
Page 7: Blade Orientation
ALIBU Step 9. Orientation of fan blades. Note that the Malibu Star fan only rotates in the clockwise direction (when looking up at the fan on the ceiling). As you face the motor a fan blade extending from the motor to you will have its leading edge on your right. -
Page 8: Wall Control Operation
1. Turn the upper knob to the desired fan speed. 2. Turn the lower knob to the desired light setting. www.CasablancaFanCo.com For questions or to locate the nearest Casablanca Authorized Service Center call toll free: 1-888-227-2178 or visit us on the web at:... -
Page 9: Troubleshooting
PROBLEM FAN WOBBLES OR SHAKES Check that blades are all set to exactly the same angle by repeating the Malibu Star section on Page 9 called ‘Blade Angle Adjustment’ . Check that blades are all correctly installed in the blade holder assembly so that their leading edge is facing the correct direction. - Page 10 761 C • P , CA 91768 ORPORATE ENTER RIVE OMONA : 888-CASA-1ST (227-2178) www.CasablancaFanCo.com ©C 2000 C • U.S. P OPYRIGHT ASABLANCA OMPANY ATENT ENDING RINTED IN...
