Ltech LT-DMX-1809 Manual page 2

LTECH
For example, Like figure 2, Set initial address to 37, Set the "1st","3rd ","6th", bit of the DIP switch
down to "1" The rest to "0" as the below figure, In this connection, the summation from 1 to 9 is 1+4+32,
Namely , The DMX512 initial address code is 37.
2. T esting function:
0
OFF
Figure 3
1 2 3 4 5 6 7 8 9 10
1 ON
ON
The DMX decoder will be entered into self control mode automatically without DMX signal input
DIP1 DIP2 DIP3 DIP4
Red Green Blue Yellow
th th
DIP8/DIP9 at "ON" (the 8 /9 DIP swithch is dowanward) is changing mode.DIP switch 1-7 has 8 levels speed changing,
DIP 7 is the fastest speed.DIP switch 1-7 at "OFF" is speed 0
DIP1 DIP2 DIP3
Speed 1 Speed 2 Speed 3
Like figure 4 , if several DIP switch at "ON", it is subject to the maximum valuei . f all DIP switch at "ON",
it is color fade effect of testing function, the speed is 7.
5. Configuration Diagram
1. LED point source conjunction diagram
DMX512
CONTROL SYSTEM
DMX512
PC SOFTWARE
IP-DMX
Data Convertor
Power adapter
Power adapter
I N 1 2 X 5 M D I N 1 2 X 5
MODEL: LT-DMX-1809
512 CHANNEL
Input Power Input Power
DC5V-24V DC5V-24V
LPD1809
Signal Output
CONNECT POWER CONNECT POWER
SUPPLIER SUPPLIER
ZHUHAI LTECH ELECTRONIC TECHNOLOGY CO., LTD.
LT- 1809 DMX512 Decoder Manual
0
OFF
1 2 3 4 5 6 7 8 9 10
1
ON ON
DIP5 DIP6 DIP7 DIP8
Purple Cyan Jumping
White
DIP4 DIP5 DIP6
Speed 4 Speed 5 Speed 6
Power adapter
M D
I N 1 2 X 5 M D
MODEL: LT-DMX-1809
512 CHANNEL MODEL: LT-DMX-1809
512 CHANNEL
Input Power
DC5V-24V
LPD1809 LPD1809
Signal Output
Signal Output
CONNECT POWER
SUPPLIER
3
Tel: +86 756 620 8823
LTECH
2. LED wall washer conjunction diagram
DMX512
PC SOFTWARE
IP-DMX
Data Convertor
Figure 4
Power adapter
I N 1 2 X 5 M D
MODEL: LT-DMX-1809
360 CHANNEL
Input Power
DC5V- 24V
DIP9
LPD1809
Signal Output
Gradual change
Hi-power wall washer
CONNECT POWER
SUPPLIER
DIP7
Speed 7
6. Attention
1. The product shall be installed and serviced by a qualified person.
2. This product is non-waterproof. Please avoid the sun and rain. When installed outdoors please
ensure it is mounted in a water proof enclosure.
3. Good heat dissipation will prolong the working life of the controller. Please ensure good ventilation.
4. Please check if the output voltage of any LED power supplies used comply with the working voltage of the product.
5. Please ensure that adequate sized cable is used from the controller to the LED lights to carry the current.
Please also ensure that the cable is secured tightly in the connector to avoid the accidents due to overheat and
poor contact on the wire.
6. Ensure all wire connections and polarities are correct before applying power to avoid any damages to the LED lights.
7. If a fault occurs please return the product to your supplier. Do not attempt to fix this product by yourself.
7. Warranty Agreement
1. We provide lifelong technical assistance with this product:
A 3 year warranty is given from the date of purchase. The warranty is for free repair or replacement and covers
manufacturing faults only.
For faults beyond the 3 year warranty we reserve the right to charge for time and parts.
2. Warranty exclusions below:
Any man-made damages caused from improper operation, or connecting to excess voltage and overloading.
The product appears to have excessive physical damage.
Damage due to natural disasters and force majeure.
Warranty label, fragile label and unique barcode label have been damaged.
The product has been replaced by a brand new product.
3. Repair or replacement as provided under this warranty is the exclusive remedy to the customer.
Ltech shall not be liable for any incidental or consequential damages for breach of any stipulation in this warranty.
4. Any amendment or adjustment to this warranty must be approved in writing by Ltech only.
★ This manual only applies to this model. Ltech reserves the right to make changes without prior notice.
Fax: +86 756 620 8833
LT- 1809 DMX512 Decoder Manual
DMX512
CONTROL SYSTEM
Power adapter
Power adapter
I N 1 2 X 5 M D
MODEL: LT-DMX-1809
360 CHANNEL
Input Power
DC5V- 24V Input Power
DC5V- 24V
LPD1809
Signal Output
Hi-power wall washer Hi-power wall washer Hi-power wall washer
CONNECT POWER CONNECT POWER
SUPPLIER SUPPLIER
4
LT@LTECHONLINE.COM
I N 1 2 X 5 M D
MODEL: LT-DMX-1809
360 CHANNEL
LPD1809
Signal Output
Hi-power wall washer Hi-power wall washer
