- Page 1 PSEN b5 PSEN sensor technology Operating Manual1002471EN03...
- Page 2 Preface This document is the original document. All rights to this documentation are reserved by Pilz GmbH & Co. KG. Copies may be made for internal purposes. Suggestions and comments for improving this documentation will be gratefully received. Pilz®, PIT®, PMI®, PNOZ®, Primo®, PSEN®, PSS®, PVIS®, SafetyBUS p®, SafetyEYE®, SafetyNET p®, the spirit of safety® are registered and protected trademarks of Pilz GmbH & Co. KG in some countries. SD means Secure Digital...
-
Page 3: Table Of Contents
Content Introduction Validity of documentation Using the documentation Definition of symbols Overview Scope Unit features Safety Intended use Installation Install safety switches PSEN cs and PSEN me Installing only safety switch PSEN cs Installing only safety switch PSEN me Dimensions in mm Technical details Order reference Product Accessories Operating Manual PSEN b5 1002471EN03... -
Page 4: Introduction
PSEN b5 Introduction Validity of documentation This documentation is valid for the product PSEN b5. It is valid until new documentation is published. This operating manual explains the function and operation, describes the installation and provides guidelines on how to connect the product. Using the documentation This document is intended for instruction. Only install and commission the product if you have read and understood this document. The document should be retained for future ref erence. Definition of symbols Information that is particularly important is identified as follows: DANGER! This warning must be heeded! It warns of a hazardous situation that poses an immediate threat of serious injury and death and indicates preventive measures that can be taken. WARNING! This warning must be heeded! It warns of a hazardous situation that could lead to serious injury and death and indicates preventive measures that can be taken. CAUTION! This refers to a hazard that can lead to a less serious or minor injury plus material damage, and also provides information on preventive measures that can be taken. NOTICE This describes a situation in which the product or devices could be dam aged and also provides information on preventive measures that can be taken. It also highlights areas within the text that are of particular import ance. Operating Manual PSEN b5 1002471EN03... -
Page 5: Overview
PSEN b5 INFORMATION This gives advice on applications and provides information on special fea tures. Overview Scope Gate mounting plate with bolt Frame plate with latch Adapter for installing PSEN cs type actuator Adapter for installing PSEN me type actuator Fastening clip Screws (M4) for installing the adapter and the fastening clip Washers and spring rings for installing the adapters Unit features The bolt consists of a Gate mounting plate with bolt and handle, which is attached to the safety gate, and a Frame plate, which is fitted to the safety gate frame. Operating Manual PSEN b5 1002471EN03... -
Page 6: Safety
PSEN b5 Fig.: Left: Bolt with safety switches assembled for left hinged gate; Right: Bolt with safety switches assembled for right hinged gate Fig.: Left: Adapter PSEN cs; Right: Adapter PSEN me The PSEN cs or PSEN me type actuator is installed on the gate mounting plate using an adapter. The corresponding safety switch is installed on the frame plate. If the operator opens the safety gate, the safety switch is actuated simultaneously. The bolt is suitable for right and left hinged gates. A padlock may also be fitted through the slot on the bolt. This stops the bolt from being opened or closed unintentionally or without authorisation. The bolt is suitable for installing on standard aluminium profiles and machine enclosures. Safety Only install and commission the bolt if you have read and understood these operating in structions plus the operating instructions for the PSEN cs safety switches and are familiar with the applicable regulations for health and safety at work and accident prevention. Operating Manual PSEN b5 1002471EN03... -
Page 7: Intended Use
PSEN b5 Please note: Do not use the safety switch and actuator as a limit stop. Always test the function with one of the approved evaluation devices. Intended use The bolt is used as a mechanical guard locking device in accordance with EN ISO 121002 and EN 1088. It is designed for use as a mechanical interlock in conjunction with a safety switch of type PSEN cs3.1 PSEN cs4.1 PSEN cs4.2 PSEN me1S PSEN me1.2S PSEN me1.21S PSEN me1M Possible combinations of safety switches The bolt can be used only with one safety switch PSEN cs only with one safety switch PSEN me or with a safety switch PSEN cs in conjunction with a safety switch PSEN me A padlock can also be used to protect the bolt from unauthorised opening and closing. The bolt may not be used on its own as a safety component to avoid hazardous plant or machine statuses. INFORMATION If PLe is required, for gate monitoring for example, a safety switch PSEN cs can also be installed in addition to a safety switch PSEN me. Installation CAUTION! Do not install the bolt until you have read and understood the operating in structions for the safety switches PSEN cs or PSEN me! Pay particular at tention to the information on operating distances and installation. Make sure that you comply with the technical details! Operating Manual PSEN b5 1002471EN03... -
Page 8: Install Safety Switches Psen Cs And Psen Me
PSEN b5 Installing the gate mounting plate and frame plate INFORMATION Installation is only possible when the bolt is open! During installation make sure that: The installation surface on the gate and gate frame is flat. The top edge of the gate mounting plate is offset against the top edge of the frame plate by 55 mm (see also Dimensions [ 14]). INFORMATION To increase manipulation protection we recommend that you make at least one screw each unusable at the gate mounting plate and at the frame plate after installation. Install safety switches PSEN cs and PSEN me [10] [11] [12] [13] Legend Actuator PSEN cs [1] Hexagonal screw M4x40 (1x) [2] Spring ring (2x) [3] Washer (2x) [4] Adapter for actuator PSEN cs [5] Fixing screw M4x10 (2x) [6] Actuator PSEN cs [7] Oneway screw M4x50 (1x) [8] Gate mounting plate with bolt and handle Operating Manual PSEN b5 1002471EN03... - Page 9 PSEN b5 Actuator PSEN me [9] Adapter for actuator PSEN me [10] Actuator PSEN me [11] Washer (2x) [12] Spring ring (2x) [13] Oneway screw M4x50 (2x) Installing the actuator 1. Install the two actuators [6] and [10] together with the corresponding adapters, as shown. 2. Secure the oneway screws [7] and [13] as shown. 3. Close the mounting holes of the actuator PSEN cs [6] using the corresponding seals. This is described in the operating manual of the safety switch PSEN cs. Installing the safety switches INFORMATION Please note the following when installing the PSENm safety switch: Align the actuator head for a left or righthinged gate prior to installation! The necessary steps are described in the operating manual of PSEN me. Legend Safety switch PSEN me Actuator head Operating Manual PSEN b5 1002471EN03...
- Page 10 PSEN b5 Legend Safety switch PSEN cs [1] Fixing screw M4x10 (2x) [2] Safety switch PSEN cs Safety switch PSEN me [3] Fixing screw M5x45 (4x) [4] Safety switch PSEN me [5] Frame plate Installing the safety switches a Install the safety switches [2] and [4] on the frame plate [5] as shown. INFORMATION To increase manipulation protection we recommend that you make at least one screw on each safety switch [2] and [4] unusable after installation. Operating Manual PSEN b5 1002471EN03...
-
Page 11: Installing Only Safety Switch Psen Cs
PSEN b5 Installing only safety switch PSEN cs Legend Actuator PSEN cs Gate mounting plate with bolt and handle Adapter for actuator PSEN cs Washer (2x) Spring ring (2x) Oneway screw M4x50 (2x) Fixing screw M4x10 (2x) Actuator PSEN cs Operating Manual PSEN b5 1002471EN03... - Page 12 PSEN b5 Installing the actuator 1. Install the actuator PSEN cs [7] together with the corresponding adapter as shown. 2. Secure the oneway screw [5] as shown. 3. Close the mounting holes of the actuator PSEN cs [7] using the corresponding seals. This is described in the operating manual of the safety switch PSEN cs. Legend Safety switch PSEN cs Frame plate Fixing screw M4x10 (2x) Safety switch PSEN cs Fixing screw M4x8 (1x) Fastening clip Installing the safety switches a Install the safety switch [3] on the frame plate [1] as shown. Operating Manual PSEN b5 1002471EN03...
-
Page 13: Installing Only Safety Switch Psen Me
PSEN b5 INFORMATION The fastening clip [5] serves to contain the plugin connection of the safety switch and the outgoing cable. The length of the cable may vary based on tolerance. Accordingly, the fastening clip [5] can be fixed in one of the holes using the fixing screw [4]. The fastening clip is available from Escha Bauele mente GmbH, order no 8047664. INFORMATION To increase manipulation protection we recommend that you make at least one screw each unusable at the gate mounting plate and at the frame plate after installation. Installing only safety switch PSEN me Installing the actuator 1. Install the actuator PSEN me together with the corresponding adapter plate as shown under "Install safety switches PSEN cs and PSEN me [ 8]". 2. Secure the oneway screw as shown. 3. Please note the details on installation listed there. Installing the safety switches Install the safety switch PSEN me on the frame plate as described under "Install safety switches PSEN cs and PSEN me [ 8]". Please note the details on installation listed there. Operating Manual PSEN b5 1002471EN03... -
Page 14: Dimensions In Mm
PSEN b5 Dimensions in mm 67.5(45-67.5) 51.8 157.5 163.5 205.25 41.8 Fig.: Installation and dimensions for PSEN b5, using a righthinged gate as an example Operating Manual PSEN b5 1002471EN03... -
Page 15: Technical Details
PSEN b5 Technical details General Approvals Mechanical data Escape release available Material Aluminium, plastic, nickelplated steel Weight 1.230 g Order reference Product Product type Features Order no. PSEN b5 Mechanical bolt, can be combined with PSEN me1, 540 015 PSEN cs3 and PSEN cs4 Accessories Product type Operation Features Order no. PSEN cs3.1a/PSEN cs3.1 Transponder techno Safety gate system, coded 541 011 logy PSEN cs3.1p/PSEN cs3.1 Transponder techno Safety gate system, coded 541 010 logy PSEN cs3.1 M12/80.15m/ Transponder techno Safety gate system, coded 541 009 PSEN cs3.1 logy PSEN cs3.1 M12/81.5m/ Transponder techno... - Page 16 PSEN b5 Product type Operation Features Order no. PSEN me1S/1AS Mechanical, spring Safety gate system, guard lock 570 000 force ing with spring force, standard actuator, supply voltage 24 VAC/DC PSEN me1.2S/1AS Mechanical, spring Safety gate system, guard lock 570 006 force ing with spring force, standard actuator, supply voltage 110 … 230 VAC PSEN me1M/1AS Mechanical, magnetic Safety gate system, guard lock 570 004 force ing with magnetic force, stand ard actuator, supply voltage 24 VAC/DC Operating Manual PSEN b5 1002471EN03...
