Drawing 3A, version D40 (scroll compressor, 1 fan) Drawing 3A, version D40 (Scroll Compressor, 1 fan, Weiguang)
Front View
Suction Line
Liquid line
Top View
X
X
X
X
Fixation
[mm]
OP-HNU ... 015D-021D
OP-HNU ... 030D
Drawing 3B, version D32 (scroll compressor, 1 fan) Drawing 3B, version D32 (Scroll Compressor, 1 fan, Weiguang)
Front View
Suction Line
Top View
X
X
X
X
Fixation
[mm]
OP-HNU ... 015D-021D
OP-HNU ... 030D
Installation & Maintenance
X Y Height H Depth D
[mm] [mm] [mm]
538
14 174 420
688
Liquid line
X Y Height H Depth D
[mm] [mm] [mm]
538
14 174 420
688
Left View
Iso View
Suction Line
X
Liquid Line
Y
Length L
[mm]
1150
Left View
Iso View
Suction Line
X
Y
Liquid Line
Length L
[mm]
1150
Air ow
Suction Line
Liquid Line
L
Air ow
Suction Line
Liquid Line
L
