Danfoss HJM022D20Q Manual page 8

Manual
Drawing 2A, version D32 (reciprocating compressor, 2 fan, Weiguang)
Drawing 2A, version D32 (reciprocating compressor, 2 fan)
Front View
Top View
Y
Suction Line
X1
Fixation
[mm]
OP-HG ... 064D-100D
25
OP-HG ... 125D-160D
Drawing 2B, version D40 (reciprocating compressor, 2 fans)
Drawing 2B, version D40 (reciprocating compressor, 2 fan, Weiguang)
Front View
Top View
Y
X1
Fixation
[mm]
OP-HG ... 064D-100D
OP-HG ... 125D-160D 25
OP-LG ... 215D-271D
8
FRCC.ES.013.A1.02
Installation & Maintenance
Suction Line
Liquid Line
Y
Liquid Line
X2 Y Height H Depth D
[mm] [mm] [mm] [mm]
715
20 500 800
971
Liquid Line
Suction Line
Y
X2 Y Height H Depth D
[mm] [mm] [mm] [mm]
715
20 500 971 800
715
Left View
Iso View
Suction Line
Length L
[mm]
1200
Left View
Iso View
Liquid Line
Suction Line
Length L
[mm]
1200
Air ow
Suction Line
H
Liquid Line
Air ow
H
Liquid Line
Suction Line
