Electrical code N, 230 V/1-ph/60 Hz; units with reciprocating and scroll compressors
SC
RC
CH
CP
Electrical code Q, 230 V/3-ph/60 Hz; units with reciprocating compressors
FC
CH CP
Installation & Maintenance
FC
FC
HP LP
FC
HP
MP
MP
LP
Legend
CP Compressor
RC Run capacitor
SC Starting capacitor
FC Fan capacitor
MP Motor protector
K Contactor
HP High-pressure switch
LP Low-pressure switch
CH Crankcase heater
RL Relay
F Fan
Legend
CP Compressor
FC Fan capacitor
MP Motor protector
K Contactor
HP High-pressure switch
LP Low-pressure switch
CH Crankcase heater
F1-F2 Fan
