System Description

Display and buttons

Communication

SRC 311 is equipped with an RJ45 connector. The connection is used to set up a network
via a wired connection. The connector contains two independent RS485 connections and
both can be used simultaneously.
™
SRC 311 - SmartRun User guide
ON key is used to start the drive.
Menu key is used to enter/exit (2 seconds) the menu and to confirm
selection/change.
Up key is used to increase a value or selection in the submenu.
OFF key is used to turn off the drive.
Down key is used to decrease a value or selection in the submenu.
Hand key is used to enter the manual mode.
Auto key is used to enter the automatic mode.
System Description
