Attaching the Battery Case to the Printer
Follow these steps to attach the battery case to the printer:
1.
Make sure the printer is turned off and close the paper support.
2.
Remove the AC adapter and the interface cable from the printer.
3.
Turn the printer over so the bottom of the printer is facing up.
4.
With the battery and interface cable compartments facing up, connect
the battery case to the printer.
Fit the power connector on the battery case into the AC adapter
receptacle on the printer.
Fit the mounting screw on the battery case into its opening on the
back of the printer.
Chapter 10
POWER CONNECTOR
MOUNTING SCREW
Installing and Using the Battery Pack
161
