DEMO MANUAL DC1620A

PERFORMANCE SUMMARY

PARAMETER
Supply Voltage—DC1620A
Analog Input Range
Logic Input Voltages
Logic Output Voltages (Differential)
Sampling Frequency (Convert Clock Frequency)
Convert Clock Level
Resolution
Input frequency range
SFDR
SNR

QUICK START PROCEDURE

Demonstration circuit 1620A is easy to set up to evaluate
the performance of the LTC2185/LTC2145 A/D converter
family. Refer to Figure 1 for proper measurement equip-
ment setup and follow the procedure below:
Setup
If a DC890 USB data acquisition and collection system
was supplied with the DC1620A demonstration circuit,
follow the DC890 Quick Start Guide to install the required
software and for connecting the DC890 to the DC1620A
and to a PC.
DC1620A Demonstration Circuit Board Jumpers
The DC1620A demonstration circuit board should have
the following jumper settings as default positions: (as
per Figure 1)
JP2-PAR/SER: Selects Parallel or Serial programming
mode. (Default: Serial)
JP3-Duty Cycle Stabilizer: Enables/Disable Duty Cycle
Stabilizer. (Default: Enable)
JP4-SHDN: Enables and disables the LTC2185/LTC2145.
(Default: Enable)
2
Arrow.com. Arrow.com.
Downloaded from Downloaded from
(T = 25°C)
A
CONDITION
Depending on Sampling Rate and the A/D Converter
Provided, This Supply Must Provide Up to 500mA
Depending on SENSE Pin Voltage
Minimum Logic High
Maximum Logic Low
Nominal Logic Levels (100Ω Load, 3.5mA Mode)
Minimum Logic Levels (100Ω Load, 3.5mA Mode)
See Table 1
Single-Ended Encode Mode (ENC– Tied to GND)
Differential Encode Mode (ENC– Not Tied to GND)
See Table 1
See Table 1
See Applicable Data Sheet
See Applicable Data Sheet
JP5-NAP: Enables and disables NAP mode (Default:
disable)
JP6-LVDS/CMOS: Selects between LVDS and CMOS output
signaling. (Default: LVDS)
Applying Power and Signals to the DC1620A
Demonstration Circuit
If a DC890 is used to acquire data from the DC1620A, the
DC890 must first be connected to a powered USB port
or provided an external 6V to 9V before applying +4.5V
to +6.0V across the pins marked V+ and GND on the
DC1620A. DC1620A requires 4.5V for proper operation.
Regulators on the board produce the voltages required for
the ADC. The DC1620A demonstration circuit requires up
to 500mA depending on the sampling rate and the A/D
converter supplied.
The DC890 data collection board is powered by the USB
cable and does require an external power supply when
collecting data from an LVDS demo board. It must be
supplied from an external 6V to 9V on turrets G7(+) and
G1(–) or the adjacent 2.1mm power jack.
VALUE
Optimized for 4.5V [4.5V 6.0V Min/Max]
1V to 2V
P-P P-P
1.3V
0.6V
350mV/1.25V Common Mode
247mV/1.25V Common Mode
0V to 3.6V
0.2V to 3.6V
