DEMO MANUAL DC1525A

PERFORMANCE SUMMARY

PARAMETER
Supply Voltage: DC1525A
Analog Input Range
Logic Input Voltages
Logic Output Voltages (Differential)
Sampling Frequency (Convert Clock Frequency)
Encode Clock Level
Encode Clock Level
Resolution
Input Frequency Range
SFDR
SNR

QUICK START PROCEDURE

Demonstration circuit 1525A is easy to set up to evaluate
the performance of the LTC2175 A/D converters. Refer to
Figure 1 for proper measurement equipment setup and
follow this procedure.
Setup
If a DC1371 QuikEval™ II Data Acquisition and Collection
System was supplied with the DC1525A demonstration
circuit, follow the DC1371 Quick Start Guide to install the
required software and for connecting the DC1371 to the
DC1525A and to a PC.
DC1525A Demonstration Circuit Board Jumpers
The DC1525A demonstration circuit board should have
the following jumper settings as default positions: (as
per Figure 1).
J13: PAR/SER: Selects Parallel or Serial programming
mode. (Default – Serial)
Optional Jumpers:
J8: Term: Enables/Disable optional output termination.
(Default – Removed)
J5: ILVDS: Selects either 1.75mA or 3.5mA of output
current for the LVDS drivers. (Default – Removed)
2
Arrow.com. Arrow.com.
Downloaded from Downloaded from
(T = 25°C)
A
CONDITION
Depending on Sampling Rate and the A/D Converter Provided,
this Supply Must Provide Up to 500mA.
Depending on SENSE Pin Voltage
Minimum Logic High
Maximum Logic Low
Nominal Logic Levels (100Ω Load, 3.5mA Mode)
Minimum Logic Levels (100Ω Load, 3.5mA Mode)
See Table 1
–
Single-ended Encode Mode (ENC
–
Differential Encode Mode (ENC Not Tied to GND)
See Table 1
See Table 1
See Applicable Data Sheet
See Applicable Data Sheet
J14: LANE: Selects either 1 lane or 2 lane output modes
(Default – Removed) NOTE: The DC1371 does not support
1 lane operation.
J15: SHDN: Enables and disables the LTC2175. (De-
fault – Removed)
J2: WP: Enable/Disables write protect for the EEPROM.
(Default – Removed)
Note: optional jumper should be left open to ensure proper
serial configuration.
Applying Power and Signals to the DC1525A
Demonstration Circuit
The DC1371 is used to acquire data from the DC1525A,
the DC1371 must FIRST be connected to a powered USB
port and have equal to 5V applied power BEFORE applying
3.6V to 6V across the pins marked V
DC1525A. DC1525A requires 3.6V for proper operation.
Regulators on the board produce the voltages required for
the ADC. The DC1525A demonstration circuit requires up
to 500mA depending on the sampling rate and the A/D
converter supplied.
The DC1525A should not be removed, or connected to
the DC1371 while power is applied.
VALUE
Optimized for 3V
[3V ↔ 6.0V Min/Max]
1V
P-P
1.3V
0.6V
350mV/1.25V Common Mode
247mV/1.25V Common Mode
Tied to GND) 0V to 3.6V
0.2V to 3.6V
to 2V
P-P
+
and GND on the
