Product Overview / Présentation Du Produit - Segway Ninebot Urban A200 User Manual

2 Product Overview / Présentation du produit
A200/A200T
Rear brake lever*
Basket
Front reflector
Headlight
Front Fender
Swappable battery
Downtube
Motor
Front wheel
* The position of the front and rear brakes di ers from country to country.
04
Dashboard
Bluetooth
Engineer repair
Phone holder
Headlight
Dashboard
Speedometer
Throttle
* Only for A200T.
Acceleration
Handlebar
Front brake lever*
Charging port
Saddle
NOTE:
Cable lock
When you press the throttle to speed up, the pedaling acceleration will be ineffective.
Reflector
Tail light
Speedometer: Displays the current speed, and error code in red if any.
Engineer repair: A lit wrench icon indicates an error.
Rear fender
Bluetooth: Shows the Bluetooth connection status.
Reflector
Headlight: The headlight's ON/OFF status is adjustable through the server command.
Pedal
Location: Flashes red when unable to locate successfully.
(with reflector)
Server connection: Flashes red when there is a network connection failure.
Speed unit: The unit is adjustable through the server command.
Status light: The light indicates the riding mode or vehicle status. The colors and meanings can be defined through the server
command. There are three modes to choose from:
Rear wheel
• Manual mode: There is no motor assistance.
• ECO Assist mode: The motor outputs 1:1 power assistance when pedaling.
Kickstand
• Turbo Assist mode: The motor outputs 2:1 power assistance when pedaling.
NOTE:
• The ratio stands for motor assistance: pedaling force. The motor assistance will increase automatically when riding up a slope.
• When the E-bike has some malfunction, all four bars of the light flash red and there will be an alarm. The motor power output
will be cut off.
Battery level:
The battery level is indicated by 5 bars, each representing approximately 20% of a full battery. When there is only one bar left,
please charge soon.
E-bike Model Accelerated by
A200 Pedaling
Pedaling or Pressing the throttle
A200T
Server connection
Location
Speed unit
Battery level
Status light
05
