3 Operating Instructions / Instructions d'utilisation

WARNING / AVERTISSEMENT
Wear an approved helmet and other protective gear to minimize any possible injury.
Portez un casque approuvé et tout autre équipement de protection pour minimiser toute blessure possible.
1 Power ON
Turn on the E-bike by sending specific commands through the server or by tapping the customized
NFC card.
When powered on successfully, the dashboard lights up and the E-bike is ready to go.
2 Adjust the Saddle Height
For a comfortable ride, when sitting on the saddle, put the heel of your foot on the pedal, the other foot
should touch the ground.
06
minimum
inserting
depth mark
WARNING / AVERTISSEMENT
DO NOT pull up the seat post higher than the minimum
inserting depth mark, otherwise, there may be a risk of
accident and injury.
NE PAS tirer la tige de selle plus haut que la profondeur
d'insertion minimale marque, sinon, il peut y avoir un
risque de accident et blessure.
3 Choose the Riding Mode
There are three riding modes to choose from. We
recommend new riders to start with ECO Assist
mode and maintain a low speed.
To turn, shift your body weight and turn the
handlebar slightly towards the direction you are
going.
Seat post
clamp
How to adjust the height:
Pull the seat post clamp outwards, adjust the saddle to
the proper height and angle, and then close the clamp
to secure the saddle.
When closed to the locked position, the clamp and the
saddle should be stable.
4 Braking
Brake by squeezing the brake lever. It is recommended
to engage both brake levers at the same time.
WARNING / AVERTISSEMENT
When braking abruptly, you risk serious injury due to loss
of traction and falls. Maintain a moderate speed and look
out for potential hazards.
Lors d'un freinage brusque, vous risquez de graves blessure
due à une perte de traction et à des chutes. Maintenez une
vitesse modérée et faites attention dangers potentiels.
07
