Specifications / Spéci Fi Cations; Certifications / Certi Fi Cations - Segway Ninebot Urban A200 User Manual

7. Specifications / Spéci fi cations
Item
Product Name
Basic
Model
Information
Dimensions: Length×Width×Height
Net Weight
Max. Payload
Applicable Height
Max. Speed
Typical Range
*
Charging Time
Vehicle
Traversable Terrain
Parameters
Max. Slope
Operating Temperature
IP Rating
Battery Type
Battery
Nominal Energy
Pack
Charging Temperature
Nominal Voltage
Motor Motor Type
System
Rated Power
Model
Input Voltage
Output Voltage
Charger
Output Current
Nominal Power
Tires
Dashboard
Others Frame Material
Front And Rear Fender
Front And Rear Brakes
* Typical Range: tested while riding with full battery, 165 lbs (75 kg) load, 77° F (25°C), 12 mph (20 km/h) on paved road, 90% discharge rate,
ECO Assist mode.
Some of the factors that affect range include rider weight, number of starts and stops, ambient temperature, etc.
16
Parameter
Ninebot Urban E-bike
A200/A200T
74 × 25 × 44 in (1885 × 640 × 1115 mm)
Approx. 84.9 lbs (38.5 kg)
243 lbs (110 kg)
5'1– 6'2 ft (155–190 cm)
Approx. 19.9 mph (32 km/h)
Approx. 50 mi (80 km)
About 4 hours
Paved road
Approx.14% (8°)
32–133°F (0–45°C)
Vehicle: IPX4: Battery pack·IPX7, motor controller IPX7, IoT IPX7
Lithium-ion battery (swappable)
551 Wh 1004 Wh
32–104°F (0–40°C) -4–122°F (-20–50°C)
36 V DC
Brushless DC geared motor
400 W (0.4 kW)
NB-42D0-05D0
100–240 V AC
42 V DC
5 A
210 W
PU filled rubber tire
LED
Aluminum
PP
Drum brake
8 Certifications / Certi fi cations
This product complies with ANSI/CAN/UL 2849:2020.
This product complies with 16 CFR PART 1512:2019.
The battery complies with UN/DOT 38.3.
The battery complies with ANSI/UL 2271.
Federal Communications Commission (FCC) Compliance Statement for USA
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
NOTE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm between the radiator and your body. This transmitter
must not be co-located or operating in conjunction with any other antenna or transmitter.
Industry Canada (IC) Compliance Statement for Canada
This device contains licence-exempt transmitter(s) that comply with Innovation, Science and Economic Development
Canada's licence-exempt RSS(s).
Operation is subject to the following two conditions:
1.This device may not cause interference.
2.This device must accept any interference, including interference that may cause undesired operation of the device.
L'émetteur exempt de licence contenu dans le présent appareil est conforme aux CNR d'Innovation, Sciences et
Développement économique Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée
17
