Technical specifications

8.1

Technical specifications of the SCALANCE XR324WG

8.1.1

24 VDC variant

The following technical specifications apply to the 24 VDC variant of the SCALANCE XR324WG.
Technical specifications
Connection to Industrial Ethernet
Electrical connectors
Diagnostics interface
Serial interface
Electrical data
Power supply
Fusing
Current consumption
Effective power loss
Permitted ambient conditions
Ambient temperature
Relative humidity
Housing, dimensions and weight
Design
Housing material
Degree of protection
Dimensions (W x H x D)
Weight
SCALANCE XR-300WG
Operating Instructions, 03/2021, C79000-G8976-C454-07
Quantity
Connector
Properties
Transmission speed
Quantity
Connector
Design
Rated voltage
Voltage range
Cable cross section
Property
During operation up to 3000 m above mean
sea level
During storage
During transportation
During operation at 25 ℃
Rack
Metal
IP30
482.6 x 43.6 x 127 mm
2700 g
24
RJ45 jack
Half/full duplex, MDI‑X pinning
10 / 100 Mbps
1
RJ-11 jack
Terminal block, 2 terminals
24 VDC
19.2 to 28.8 VDC Safe Extra Low Voltage (SELV)
≥ 0.75 mm
(20 AWG)
2
Implemented redundantly
5 A / at least 60 V
Or power supply with LPS or NEC class 2
300 mA
7.2 W
0 ℃ to +60 ℃
-40 °C to +85 °C
-40 °C to +85 °C
≤ 95% without condensation
8
71
