DIGITAL CLAMPMETER
+ MULTIMETER
KM 181
OPERATION
MANUAL
®
Advertisement
Table of Contents
Related Manuals for Kusam-meco KM 181
Summary of Contents for Kusam-meco KM 181
- Page 1 * Thermo Anemometer DIGITAL CLAMPMETER * Thermo Hygrometer * Distance Meter + MULTIMETER * Digital Lux Meter KM 181 * Network Cable Tester * Power Factor Regulator * Earth Resistance Tester * Digital Panel Meters * DC Power Supplies * High Voltage Detector...
- Page 2 If you incorrectly connect your clamp meter to a circuit, or if you have the clamp meter on KM 181 wrong setting, you damage the meter and possibly hurt yourself. You can also get into trouble if you try to measure the voltage across a charged capacitor.
-
Page 3: Table Of Contents
Examples are measurements on distribution boards, circuit-breakers, wiring, including cables, bus-bars, junction boxes, switches socket-outlets in the fixed installation, & equipment for industrial use & some other equipment, for example, stationary motors with permanent connection to the fixed installation. KUSAM-MECO April 2011 KUSAM-MECO April 2011... - Page 4 Application around and removal from part during measurement. Inspect test leads, hazardous live conductors is permitted. connectors, and probes for damaged insulation or exposed metal before using the instrument. KUSAM-MECO April 2011 KUSAM-MECO April 2011...
-
Page 5: Features
Safety : Double insulation per IEC61010-1 2 Ed., EN61010-1 2 Ed., Ul61010- 2 Ed. & CAN/CSA C22.2 NO.61010.1-0.92 to CAT III 600V and CAT IV 300V AC & DC Transient Protections : 6.0kV(1.2/50 s surge) KUSAM-MECO April 2011 KUSAM-MECO April 2011... -
Page 6: Electrical Specification
Impedance increases abruptly within a fraction of a second as display voltage is above 50V(typical). Accessories : Test leads(pair),User's Manual. Ended up impedances vs display voltages typically are: Optional Accessories: PC Interface, @100V USB interface kit BRUA-13X. 100k @300V 250k @600V KUSAM-MECO April 2011 KUSAM-MECO April 2011... - Page 7 50V(typical). Ended up impedances Vs display voltages typically are : @100V Audible Continuity Tester 100k @300V Response Time Audible Threshold 250k @600V 32ms approx. between 10 and 200 KUSAM-MECO April 2011 KUSAM-MECO April 2011...
- Page 8 (Typical) Voltage indication of live wires, such as distinguishing between live and ground connections, use the <1.8V DC typical 1.000V 0.56mA Red (+) test probe for direct contact measurement. Accuracy : 1.0% + 3d KUSAM-MECO April 2011 KUSAM-MECO April 2011...
-
Page 9: Product Description
9) Jaw center Indicators, at where best ACA ACA function accuracy is specified Set the slide-switch to select ACA function. Input 10) Jaw marking lines for ACA position error is made through the clamp jaws for non-invasive indication current measurements. KUSAM-MECO April 2011 KUSAM-MECO April 2011... - Page 10 CREST CREST measurement accuracy. Keep the jaws away from HOLD HOLD them as much as possible to minimize influence. PC-Comm PC-Comm 3. 8 02 2. 0 08 RANGE RANGE Auto Auto KUSAM-MECO April 2011 KUSAM-MECO April 2011...
- Page 11 *As Hazardous- Alert: When making resistance measurements in Auto- Check mode, an unexpected display of voltage readings alerts you that the object under test is being energized. KUSAM-MECO April 2011 KUSAM-MECO April 2011...
- Page 12 Auto CREST HOLD CREST CREST CREST HOLD HOLD HOLD PC-Comm PC-Comm PC-Comm PC-Comm 63. 1 060. 2 3. 2 26 0. 6 03 3. 8 02 RANGE RANGE RANGE Auto RANGE Auto Auto Auto KUSAM-MECO April 2011 KUSAM-MECO April 2011...
- Page 13 Capacitance function in a live circuit will Auto Auto produce false results and may damage the meter. In many cases the suspected component(s) must be disconnected from the circuit to obtain an accurate measurement reading. KUSAM-MECO April 2011 KUSAM-MECO April 2011...
- Page 14 Red (+) test probe for direct contact Relative-Zero mode allows the user to offset the measurements. meter consecutive measurements with the main display displaying reading as the reference value. Press the REL button momentarily to toggle Relative-Zero mode KUSAM-MECO April 2011 KUSAM-MECO April 2011...
-
Page 15: Maintenance
Auto-Power If self diagnostic massage “C_Er” is being Off (APO) feature. Turn the slide switch OFF and displayed while powering on, some meter ranges back on to resume. might be largely out of specifications. KUSAM-MECO April 2011 KUSAM-MECO April 2011... -
Page 16: Test Certificate
Lr03) battery X 2. Loosen the 2 captive screws from the to national standards. battery cover case.Lift the battery cover case Replace the batteries. Replace battery cover case. Re-fasten the screws. KM 181 MODEL NO. ___________ SERIAL NO. ___________ DATE: ___________... -
Page 17: Warranty
WARRANTY “KUSAM-MECO’s” warranty obligation is limited, at option, free of charge repair, or replacement of Each “KUSAM-MECO” product is warranted to be a defective product which is returned to a free from defects in material and workmanship “KUSAM-MECO” authorized service center within under normal use &...
