An ISO 9001:2015 Company
KM 1001 Digital Clampmeter is completely portable, 3½ Digit LCD display meter.
This Clampmeter is designed for us in the Laboratory, Field servicing, at home, under any
circumstance where high current measurement is required. This meter is built with a design
of finger guard which ensures safety operating & electronic overload protection for all
function & range. In addition, a carrying case is available for easy portability of the
meter & avoiding damage. Rugged Fire retardant & Shock Resistant casing.
GENERAL SPECIFICATIONS :
— Display : 3½ Digit 2000 counts LCD with automatic polarity indication.
— Measuring Method : Dual-slope integration A/D converter system.
— Over range indication.
— Over load protection : Protected by PTC in the resistance range.(protection upto 500V AC RMS).
—
Data Hold function : the hold & release for all display data is performed alternatively by "D.H" push switch..
—
Low battery indication : The "BATTERY" symbol is displayed when the battery voltage drops below accurate operating level.
—
Continuity function.
—
Power Supply : 9V Alkaline or carbon-zinc battery.
— Operating
Temperature & Humidity : 0°C ~ 50°C; 80% max. R.H.
— Storage
Temperature & Humidity : -20°C ~ 60°C; 80% max. R.H.
— Accessories :
User Manual, Battery & Carrying case.
ELECTRICAL SPECIFICATIONS :
AC CURRENT
Range
Resolution
20 A
200 A
0.1 A
400 A
AC VOLTAGE
Range
Resolution
600 V
1 V
®
An ISO 9001:2015 Company
Chhaya com/D/chhaya/my documents/chhaya/backup/catlog/New catlog/2015 new arrival catalogs/KM 1001.cdr
400A AC DIGITAL CLAMPMETER
RESISTANCE
Accuracy
50 W ~ 2000 W
±(1.5% rdg + 4 dgts)
DC VOLTAGE
Accuracy
±(1.5% rdg + 4 dgts)
G-17, Bharat Industrial Estate, T. J. Road, Sewree (W), Mumbai - 400 015. INDIA.
Sales Direct.: 022-24156638,
Email : kusam_meco@vsnl.net,
Range
Resolution
±(1.0% rdg + 2 dgts)
1 W
Range
Resolution
±(1.0% rdg + 2 dgts)
600 V
1 V
All Specifications are subject to change without prior notice.
Tel. : 022-24124540, 24181649,
MODEL-KM 1001
Preliminary Data
Accuracy
Accuracy
Fax : 022-24149659
Website : www.kusamelectrical.com
