Kusam-meco KM 1120 Operation Manual

An ISO 9001:2008 Company
ETCR Clamp Earth Resistance Tester is widely applied in ground resistance measurement, loop resistance
measurement in fields such as electric power, telecommunications, meteorology, oil field, architecture and
industrial electrical equipment, etc. When measuring ground system with loop, there is no need to disconnect
the ground wire without auxiliary electrode, which means safer and faster. KUSAM-MECO Clamp Earth
Resistance Tester can measure the ground fault which can not be measured by traditional method, can apply in
the occasion where traditional methods are unworkable; KUSAM-MECO Clamp Earth Resistance Tester
measures the integrated value of ground resistance and resistance lead. Tester can measure the leakage
current of ground wire.
GENERAL SPECIFICATIONS :
— Display : 4 digit LCD Backlight Display.
— Jaw Opening : 65 x 32 mm.
— Span of Jaw : 32 mm.
— Structural Feature : In the jaw way.
— Operating temperature : -10 C ~ 55 C
— Relative humidity
— Protection grade
— Range selection
— External Magnetic Field : < 40A/m
— External Electric Field : <1V/m
— Sampling Time
— Measurement Resistance Frequency
— Max. Resistance Measurement Resolution : 0.001W
— Resistance Measurement Range
— Current Measurement Range
— Measured Current Frequency
— Storable Measurement Data
— Setting range of Resistance Alarm Critical value : 1 - 199W (KM 1220)
— Setting Range of current Alarm Critical Value
— Power Supply : 6VDC ( 4 x 5 Alkaline Battery).
— Dimension : 285 (L) X 85 (W) X 56 (T)mm.
— Weight : Approx. 1160g. (including batteries)
ELECTRICAL SPECIFICATIONS :
RESISTANCE
Measurement
Range (W)
0.010~ 0.099
0.10~ 0.99
1.0 ~ 49.9
50.0 ~ 99.5
100 ~ 199
200 ~ 395
400 ~ 590
600 ~ 1000
®
An ISO 9001:2008 Company
Chhaya com/D/chhaya/my documents/chhaya/backup/catlog/New catlog/2015 new arrival catalogs/KM 1120/km 1220.cdr
o o
: 10% ~ 90%RH
: double insulation
: Automatic
: 1 second
: >1kHz
: 0.010 ~ 1000W
: 0.00 - 20.0A (KM 1220)
: 50 / 60Hz (KM 1220)
: 99 units (KM 1220)
: 1 - 499mA (KM 1220)
Accuracy
Resolution
(W)
(W)
0.001 ±(1% + 0.01W)
0.01 ±(1% + 0.01W)
0.1 ±(1% + 0.1W)
0.5 ±(1.5% + 0.5W)
1 ±(2% + 1W)
5 ±(5% + 5W)
10 ±(10% + 10W)
20 ±(20% + 20W)
G-17, Bharat Industrial Estate, T. J. Road, Sewree (W), Mumbai - 400 015. INDIA.
Sales Direct.: 022-24156638,
Email : kusam_meco@vsnl.net,
EARTH RESISTANCE TESTER
MODEL - KM 1120 / KM 1220
W
CURRENT RANGE MEASUREMENT (KM 1220)
Measurement
0.00 - 99mA
100 - 299mA
0.30 - 2.99A
3.00 - 9.99A
10.00 - 20.00A
Tel. : 022-24124540, 24181649,
CLAMP-ON TYPE
Preliminary Data.
Resolution
Range (W)
(W)
1mA
1mA
10mA
10mA
10mA
All Specifications are subject to change without prior notice.
Website : www.kusamelectrical.com
Accuracy
(W)
±(2.5% + 5mA)
±(2.5%+10mA)
±(2.5%+0.1A)
±(2.5%+0.2A)
±(2.5%+0.3A)
