Kusam-meco KM 175D Operation Manual

Ac true rms digital clampmeter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
An ISO 9001:2008 Company
SPECIAL FEATURES :
TM
— AmpTip low-current range.
— Backlighted LCD display.
— Duo-Core to simultaneously measure clamp-on Amps + A DMM functions.
— VFD-V & Hz for fundamental V/Hz of most Variable-Frequency-Drives
— Display Hold & Non-Contact EF-Detection (NCV)
— AC True RMS Voltage & Current functions.
— Fast 80ms Peak-RMS mode to capture in-rush currents
— Probe contact EF-Detection for more precise indication of live.
— Line level ACV frequency 10.00Hz to 999.9Hz.
— Cx ranges 200.0mF to 2500mF for start & Run Motor Capacitors.
GENERAL SPECIFICATIONS :
í Sensing :
True RMS
í
Jaws Opening size & conductor diameter : 30mm Max.
í
Display : 3-5/6 digits 6000 counts; dual display
í
Update Rate : 5 per second nominal
í
Polarity : Automatic
í
Operating Temperature :
0ºC to 40ºC
í
Relative Humidity : Maximum 80%R.H. for temperature upto 31°C
decreasing linearly to 50% R.H. at 40°C.
í
Altitude : Operating below 2000m
í
Storage Temperature : -20°C ~ 60°C, < 80% R.H. (with battery removed)
í
Temperature Coefficient : Nominal 0.15 x (specified accuracy) / C @ ( 0 C –– 18 C or 28 C –– 40 C),
or otherwise specified.
í
Power Supply : Standard 1.5V AAA Battery x 2
í
Power Consumption : typical 6.2mA
í
Low Battery :
Below approx. 2.85V for Capacitance & Hz
Below approx. 2.5V for other functions
í
APO timing : Idle for 32 minutes approx.
í
APO Consumption : typical 5mA.
í
Dimension : 217(L) x 76(W) x 37(H)mm
í
Weight : approx. 189 gms.
SAFETY :
—
Safety :
Double insulation per UL/IEC/EN61010-1 Ed. 3.0, CAN/CSA C22.2
No. 61010-1 Ed. 3.0, UL/IEC/EN61010-2-032 Ed. 3.0 & UL/IEC/EN61010-2-033 Ed. 1.0
CAT III 600V & CAT Iv 300V AC & DC.
—
E.M.C. :
Meets EN61326-1 : 2013
Temperature function at 80MHz ~ 150MHz :
In an RF field of 1V/m :
Total Accuracy = Specified Accuracy + 25 digits
Other Functions:
In an RF field of 3V/m :
Total Accuracy = Specified Accuracy + 20 digits
—
Overload Protection :
Clamp-on jaws : 600A rms continuous
"+" & COM Terminals (all other functions): 600VDC/VAC rms
—
Pollution Degree : 2
—
Transient Protection : 6.0kV (1.2/50ms surge)
—
Rugged Fire retarded casing.
—
LVD EN61010-2-032 / EN61010-1 to CAT III 600V & CAT IV 300V
ACCESSORIES : Test leads set, Users Manual, Carrying Case, Bkp60 banana plug K-type thermocouple.
OPTIONAL ACCESSORIES : BKB32 banana plug to type-K socket plug adaptor.
®
An ISO 9001:2008 Company
Chhaya com/D/chhaya/my documents/chhaya/backup/catlog/New catlog/2015 new arrival catalogs/KM 175D.cdr
®
o
G-17, Bharat Industrial Estate, T. J. Road, Sewree (W), Mumbai - 400 015. INDIA.
Sales Direct.: 022-24156638,
Email : kusam_meco@vsnl.net,
AC TRUE RMS DIGITAL CLAMPMETER
o
o
o
o
All Specifications are subject to change without prior notice
Tel. : 022-24124540, 24181649,
MODEL KM 175D
Preliminary Data
Fax : 022-24149659
Website : www.kusamelectrical.com
