Table Of Contents - Axxess ASWC-1 Installation Manual

Preface
.............................................................................................. 3
Overview
- Introduction to the ASWC-1 Interface and Wiring Harness ..............4-5
ASWC-1
- Section 1: Installation ....................................................................6-7
- Section 2: Programming ................................................................8-9
- Section 3: Troublshooting
Auto Detect Mode ...................................................................... 10
Manual Programming ...........................................................10-13
Changing Radio Type ............................................................13-14
Manual Radio Type Programming .........................................14-15
- Section 4: Remapping
Remapping SWC Buttons ........................................................... 16
Resetting Original SWC Settings ................................................ 17
ASWC-1 Legend
- Vehicle LED Feedback ..................................................................... 18
- Radio LED Feedback ..................................................................18-19
- Button Assignment (remapping/manual programing) ....................... 19
- Dual Assignment Instructions .....................................................20-21
Caution: Metra recommends disconnecting the negative battery terminal
before beginning any installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before reconnecting the battery or
cycling the ignition.
Note: Refer to the instructions included with the aftermarket radio.
