Setting the Trim

Editing the trim settings menu allows you to turn the trim pop‑up
on or off, change the length of time the pop‑up window remains
on the screen, turn the high resolution on or off, and calibrate the
gauge to the sensor. A high resolution setting will cause the
monitor to display the trim position with more detailed
information.
1. While in the "Main Menu," press the "–" or "+" button to
highlight the "Settings" menu.
2. Press the "MODE" button to enter the "Settings" menu.
3. Press the "–" button to highlight the "Trim" menu.
SETTINGS
NOTE: The favorites slide seconds must be displayed for the
favorites screen transition to function. Select from 1–30
seconds to display the selected favorites. When the seconds
are set to "OFF," the favorites screen must be advanced
manually using the mode button.
Main Menu
Propulsion / ST
Vessel
Favorites
Alarms
!
Settings
MODE
