  • Page 3: Table Of Contents

    Installation & Commissioning of Control & Monitoring Add On’s Table of Contents Page No. About This Manual....................2 Purpose .......................2 Scope ........................2 References ......................2 PCB Removal / Replacement................3 Wiring to the Main Card BRD25MCB ..............3 Communications ....................3 Adding Control and Monitoring Facilities ............4 Internal Communications Connector (RS485)..........4 Programming ......................4 Installation and Wiring of Add On Cards and Boards ........

  • Page 4: About This Manual

    References ZoneSense PLUS Technical Manual ZoneSense PLUS Operation & Programming Manual ZoneSense PLUS Installation and Commissioning Manual Apollo Detector / Device Manuals Ampac Product Data Sheets British Standard EN54 Parts 2 & 4 European Standard BS 5839 NORMAL ENABLE DELAY...

  • Page 5: Pcb Removal / Replacement

    Installation & Commissioning of Control & Monitoring Add On’s PCB Removal / Replacement If the PCB’s have to be removed the following precautions should be observed; Removing the door will provide better access to the boards and ensure the hinges are not accidentally stressed.

  • Page 6: Adding Control And Monitoring Facilities

    Installation & Commissioning of Control & Monitoring Add On’s Adding Control and Monitoring Facilities A combination of one of each type of board / card, but not all of them, can be mounted on the back pan or the front panel of the FACP to provide additional features to a standard panel. All board inputs or outputs are programmable to any combination of zones.

  • Page 7: Address Setting And Terminating The Communications Bus

    Installation & Commissioning of Control & Monitoring Add On’s Address Setting and Terminating the Communications Bus Address Setting ( SW1 ) ZoneSense PLUS Except for the LED Mimics in FACP’s there can only be one (1) Board / Card of each type so the address on each board is set to 1.

  • Page 8: Input Board Brd25Sipb

    Taking note of the Common 0v terminals connect the voltage free contacts as shown below. Note: only the first 8 are functionally programmable in ZoneSense PLUS There can only be 1 Input Board so the address on each board is set to 1.

  • Page 9: Fire Fan Module Brd25Fcb

    Installation & Commissioning of Control & Monitoring Add On’s Relay Board ( Remote ) BRD25EWRB - B In the remote version the Comms In and Out Terminal Block TB9 is cabled to the RS 485 Comms terminal block TB3 on the Main Card 302 – 7690 or LED Mimic and can be installed up to 1.2kms from the FACP.

  • Page 10: Fan Termination Board Brd25Ftb

    Installation & Commissioning of Control & Monitoring Add On’s Fan Termination Board BRD25FTB The Fan Termination Board interfaces between the Fire Fan Module and the plant/equipment it controls via the 24 volt 250mA Start, Stop, current limited, relay outputs and monitor inputs. Programmable monitoring of the field equipment is achieved using 0 volts as an input level to indicate run, fault and stop conditions of that equipment.

  • Page 11: Switch And Indicator Card Brd25Gib - B

    Installation & Commissioning of Control & Monitoring Add On’s Switch and Indicator Card BRD25GIB - B This Card can effectively perform 2 different functions. Firstly the indicators monitor the first 8 inputs of the 16 Way Input Termination Board while secondly the switches can be programmed to manually operate a specific relay in the system.

  • Page 12: Zone Mimic Indicator Card ( Externally Powered. ) Brd25Gib -C

    Installation & Commissioning of Control & Monitoring Add On’s Zone Mimic Indicator Card ( Externally Powered. ) BRD25GIB -C The externally powered Zone Mimic Indicator Card operates in the same way as does the internally powered version. The only difference is that the 27 volt power supply is independent of the FACP.

  • Page 13: Sounder Board Brd25Sopb -A

    Installation & Commissioning of Control & Monitoring Add On’s 4.11 Sounder Board BRD25SOPB -A The Sounder Board expands the number of sounders that can be used on an FACP to 8. Each solid state output is rated at 24VDC / 500mA. and requires a 10KΩ End of Line (EOL) resistor regardless whether or not a sounder is wired to the circuit.
  • Page 14 Installation & Commissioning of Control & Monitoring Add On’s Disabled Mode Disabled mode is selected by placing the keyswitch at the Agent Release Module in the Disabled position. This electrically isolates the activation circuit, and results in the following: Disabled indicators at the Agent Release Module and Local Control Station are lit. Agent Release Module and Local Control Station buzzers sound.
  • Page 15 Installation & Commissioning of Control & Monitoring Add On’s When the second zone goes into alarm, then the following steps are followed Auto release activated LED on the Agent Release Module and Local Control Station goes steady Stage 2 outputs are pulsed during the pre-release delay to +24VDC Start optional pre-release delay.

  • Page 16: Agent Release Module Brd25Arb - A

    Installation & Commissioning of Control & Monitoring Add On’s Isolation If the trigger zones are isolated by the FACP, then the trigger zone isolated indicator at the Agent Release Module and Local Control Station is illuminated, and the system inoperative output is operated.

  • Page 17: Local Control Station Brd25Arb - B

    Installation & Commissioning of Control & Monitoring Add On’s Agent Release Module PCB Layout The PCB is fitted with two 2 x RJ45 connectors CN6 & 7 for power (27VDC) and communications (RS485) for communications between the Module and the FACP Main Card. Quiescent Current: 28.5mA RS485 &...

  • Page 18: Common Agent Release Module And Local Control Station Indicators

    Installation & Commissioning of Control & Monitoring Add On’s Common Agent Release Module and Local Control Station Indicators MANUAL RELEASE Manual Release Activated ACTIVATED Red in colour. Lit when a manual agent release sequence has commenced. This can be instigated from the Agent Release Card and Local Control Station. AUTO RELEASE ACTIVATED Auto Release Activated...

  • Page 19: Agent Release Termination Board Brd25Atb

    Installation & Commissioning of Control & Monitoring Add On’s Local Control Station Terminal Blocks TB1 & TB2 TB2 Terminal Assignment TB1 Terminal Assignment RS485 + In +27V In RS485 - In 0V In RS485 Common +27V Out RS485 + Out 0V Out RS485 - Out RS485 Common...

  • Page 20: Interface Wiring

    Installation & Commissioning of Control & Monitoring Add On’s The Agent Release Termination Board interfaces to the; The FACP via CN1, CN2 continuing the RS485 communications bus if required. LK1 is inserted if this is the last backpan board on the bus. LCS’s ( up to 4 ) via TB1.
  • Page 21 Installation & Commissioning of Control & Monitoring Add On’s Solenoid & Metron This input relies on N/O or N/C relay contacts used in conjunction with 22KΩ EOL and 4K7Ω series resistors. The type of agent release mechanism and contacts used has to be set in the Programming Menu for the input to function as per the manufacturers specifications and be in accordance with the relevant Standard.

  • Page 22: Appendix: Adding To The System Menu & Programming

    Installation & Commissioning of Control & Monitoring Add On’s Appendix: Adding to the System Menu & Programming In this example 1 Input Board, 1 Relay Board and 1 Sounder Board will be added to the system. The Display and Zone Labels will then be edited. Step 1: Go to the SYSTEM MENU and then follow the procedure as set out below.
  • Page 23 Installation & Commissioning of Control & Monitoring Add On’s Step 2 LEGEND: PROGRAM MENU ISOALTE PRESS ACF TO ISOLATE CIRCUITS EXTERNAL TO FACP ENTER MENU ENTER CANCEL PRESS CANCEL AT ANY TIME TO BACK OUT OF THE MENU CANCEL ISOALTE ZONES MENU PRESS ENTER TO GO TO SUB MENU, SET MENU OR UPDATE PROGRAM...

  • Page 24: Status And Programming Screens

    Installation & Commissioning of Control & Monitoring Add On’s Status and Programming Screens The following shows all the screens that are possible in the FACP and how to navigate through them. I f a screen is not available it means that option has not been installed or is not available to the model in use.

  • Page 25: Level 3 System Programming

    Installation & Commissioning of Control & Monitoring Add On’s Level 3 System Programming ENTER ALARM MENU RESOUND MENU MENU SYSTEM BUZZER ENTER PASSWORD ENTER YES / NO ENTER YES / NO FACTORY DEFAULT EXAMPLE PASSWORD IS 3333 SET RESOUND TO YES THEN MOVE TO ALARM EXAMPLE OF Y E S...

  • Page 26: Level 3 Programming Menu

    Installation & Commissioning of Control & Monitoring Add On’s Level 3 Programming Menu PROGRAM MENU ENTER SELECT DOUBLE MENU ZONE S AGENT T2 ZONE 1 - 8 NON LATCH AGENT T1 KNOCK ENTER NORMAL 1 TO 8 LEGEND: MENU SELECT ISOALTE PRESS ACF TO ISOLATE CIRCUITS EXTERNAL TO FACP Z O N E SELECT...
